Range
- Insulation voltage up to 24 kV.
- Primary nominal currents up to 12.000 A. Higher current possible.
- Secondary currents 1 and 5 A.
- Frequencies: 50 Hz, 60 Hz.
Applications
- Power generation.
Advantages
- Measuring and protection applications.
- Designs with good behaviour in ambient temperatures up to 80ºC.
- Stainless steel screws available.
|
|
Indoor current transformers up to 40.5 kV
Description
Comprehensive range of indoor current tranformers, for measurement and protection.
Compliance with IEC 60044-1 standard
Rated current: from 5 to 5000 A
Reference voltage for isolation: up to 36kV - 40.5kV Optimised design et perfomances:
Standard shape
Optimised dimensions
Suitable for use in all type of MT cubicle and in harsh environments:
Metalclad units
Metal enclosed units
Environments with potentially explosive atmosphere.
|
|
Outdoor Medium Voltage Instrument Transformers. Dry Type
Dry Insulation Transformers are designed to produce a scaled down replica of the current in the power line and isolate the measuring instruments, meters, relays, etc. from the high voltage power circuit.
|
|
Outdoor current transformers up to 40.5 kV
Description
Comprehensive range of outdoor current tranformers:
Compliance with IEC 60044-1 standard
Rated current: from 5 to 2500 A
Reference voltage for isolation:up to 40.5kV
Optimised design et perfomances:
Creepage distance in accordance with pollution level IV
Extremelly good ageing behaviour thanks to silica surface coating.
|
|
Product for marine and off-shore application.
Distribution, Propulsion transformers
6, 12, 24 pulse.
High reliability expecially looking at the insulation characteristics
of the transformers.
AN-AF-ANWF cooling system
IP00 to ip55
Aluminium or Copper windings.
|
|
Product for marine and off-shore application.
Distribution, Propulsion transformers
6, 12, 24 pulse.
High reliability expecially looking at the insulation characteristics
of the transformers.
AN-AF-ANWF cooling system
IP00 to ip55
Aluminium or Copper windings.
|
|
|
|
