Celeron M 1.0GHz CPU embedded, Fan-less High Speed Box Computer
These products are IBM PC/AT-compatible box computers designed for industrial use based on a low-power-consumption CPU of the Ultra Low Voltage Intel(R) Celeron(R) M Processor 1.0GHz (FSB400MHz), to operate as a completely nature-cooled (fanless) system. The box computers provide a variety of
interfaces including the USB2.0, 100BASE-TX, and RS-232C ports, capable of serving for a wide range of applications as a compact platform based on a general-purpose PC OS.
As this series incorporates handpicked components such as the embedded types of CPU and chipset, these products excel in environmental resistance and remains in stable supply for an extended period of time. You can therefore use the box computer under severe operating conditions such as FA with ease.
CPU: Ultra Low Voltage Intel(R) Celeron(R)M Processor 1.0GHz, FSB400MHz
Chip: set Intel(R) 855GME
Memory: 512 MB standard Max.1GB, 2.5V 184-pin DDR SDRAM PC2700 ECC supports
COM port: 4ch RS-232C
LAN: 100BASE-TX/10BASE-T
USB: 6ch
Dimensions (mm): 262(W) x 262(D) x 55(H) [IPC-BX700-AC]
Weight: About 3.3kg
|
|
|
|
|
|
Features:
Onboard VIA Eden V4 1 GHz CPU
VIA CN700 VT8251 Chipset
One SODIMM up to 1 GB DDR2 SDRAM
5.1 CH Audio
Dual Realtek RTL8111B PCI-E Gibabit LAN
1 Mini PCI, Type I/II CF
1 COM, 3 USB 2.0
Supports 2.5" SATA HDD
Fanless & Single 5V Operation
Specifications
System
CPU VIA Eden V4 1 GHz CPU
BIOS Award
System Chipset VIA CN700/VT8251
System Memory One 200-pin SODIMM supports up to 1 GB DDR2 400/533 SDRAM
SSD One CompactFlash Type I/II socket with ejector
Watchdog Timer Reset: 1 ~255 min.
H/W Status Monitor Monitoring system and CPU temperature, voltage, Auto throttling control when CPU overheats
Display VIA ProSavage CN700 integrated 2D/3D gaphic engine
Audio AC97 Codec, 5.1 CH Audio
Ethernet Dual Realtek RTL8111B
System Indicators 2 LED indicators show the power and HDD
Drive Bay Mounting kit for one 2.5" HDD (hidden)
Expansion Interface One Mini PCI slot
External I/O
Serial Port 1 x RS-232, 1 x RS-232/422/485, Setting by BIOS
LAN Port 2 x RJ-45
VGA/LCD Port 1 x DB-15
Audio Port Mic in, Line in, Line out
USB Port 3 x USB 2.0
Mouse & KB 1 x PS/2 mini DIN
Power Input 100 ~ 240 Vdc / 50 ~ 60 Hz
Power Output +5 Vdc / 8 A (40W)
Environment & Mechanical
Power Consumption +5V@4.08A (with VIA Eden V4 1.0 GHz & 256MB DDR2 533 SDRAM)
Dimension (WxDxH) 7" x 4.4" x 2.0" (178 x112 x50 mm)
Weight 2.7 lbs (1.2 Kgs)
Mounting Desktop
|
|
BC17BN
- Fanless system that specially targets for the business that operate under harsh environments and require maximum reliability.
- Compact size for any application.
- Intel Atom N270 low power consumption processor delivers outstanding performance for hospitality and retail business.
- Numerous mounting designs fit most of the requirement
|
|
|
|
|
|
JetBox 8150/8152 is a VIA Eden V4 1GHz based computer with system memory 1GB DDRII RAM and built-in high performance media processor to speed up the graphic related work. The industrial computer has a compact design with rich interface, including Ethernet ports, USB2.0, RS-232, RS232/422/485, VGA, and high resolution audio. JetBox 8152 also integrates a special slot for expanding the memory by SATA Hard Drive.
Besides, Korenix new JetBox 8152 1GHZ Industrial Communication Computer is equipped with CANbus port for longer distance data transmission with high security and reliability.
To make the deployment of JetBox 8150/8152 more flexible and easily manageable for software engineers, the devices are deigned to support dual operating systems – Windows XP and Linux Fedora 10. The ready-to-use softwares provide abundant networking related protocols for improving the usability of embedded computers in industrial computing.
Main features of JetBox8152 are:
- High Performance Multimedia Processor
# VIA Eden V4 1GHz, 128K L2 cache
# Multimedia processor CX700M
# DDR2 1GB (200-pin SoDIMM)
# Max. 128MB VGA memory
# High resolution audio
- Sophisticated Enclosure for Demanding Operation
# Fan-less, aluminum heat-sink frame housing to enhance heat dispersion
# Industrial design for anti-vibration & anti-shock
- Abundant Interfaces to Integrate Connectivity
# Dual Ethernet, 1 COM, 1 CAN, 2 USB
# 1 CompactFlash Card Type I/II Socket
# 1 SATA (2.5" HD option)
# 2 Audio connectors
# (Mic/ Line-in & Line-out)
- Ready-to-use
# Windows XP embedded with system development kit
# XPe CANbus (Optional)
# Linux Fedora10 with VPN
# Linux CANbus (optional)
|
|
As a systems provider, Jetter AG offers you a great variety of devices for operation and visualization. From small alphanumeric devices, to graphic user interfaces which can be operated as terminals and linked to a server, up to ruggedized industrial computers.
For more than 20 years, the EBELT division of Jetter AG develops and manufactures components for industrial automation systems: Counters, text displays, serial HMIs.
About 6 years ago we started supplying the automotive industry which has set high standards as to temperature, shock, EMC and operatability.
The Industrial PC lends itself for visualisation and data management, as well as for a platform for a Soft PLC.
The JetView Product range contains compact devices of the JetView series, as well as Panel PCs and devices for the electric cabinet of the JetIpc series, with remote display or as panel version.
|
|
Embedded Box PCs
Kontrons Box PCs are suitable for machine, cabinet building factory automation, offering scalability in performance, connectivity and size. Kontrons Box PCs fit nearly all applications in industrial environment. When EMC, temperature, Vibration and schock become an issue, Kontrons Box PCs are the right choice.
|
|
|
|
|
|
Exquisite Look
Following the development of Avalue's EPC series product line, EPC-945 expresses compact style, just sized in 178mm x 142mm x 50mm. This features more flexibility at versatile spaces and applications. Besides, the size of EPC series fits in standard vehicle specification, 1 DINN, to be easily embedded into a car becoming a full-functional car computer by removing external aluminum case.
Trusted Performance
Adopted Avalue's 3.5 inch single board computer module, an EPC-945 is optimized by Intel® dual-core processors, and supports up to 2GB DDR2 memory. It provides with benefits to customers, such as low costs, low power consumption, low temperature, low break down rate, high performance and reliability of transmission speed, etc. Therefore, EPC-945 is used in wide range of embedded mini PC applications, like interactive clients, gaming platforms, and industrial automation equipments.
Excellent Expandability
The 945GME chipset integrates 3D graphics engine, GMA950 architecture; supports high resolution up to 2048 x 1536. EPC-945 also supports dual independent displays configuration, CRT + LVDS. ICH7-M delivers outstanding system performance through high-bandwidth interfaces. Three sets of USB, one set of Compact Flash, one set of Mini PCI and video output interfaces; keyboard/mouse and microphone audio input interfaces; two sets of gigabit high-speed LAN present the excellent operating platform for a variety of multimedia and communication applications.
|
|
|
|
|
|
Fanless Intel® 852GM Celeron® M 600 MHz Micro PC
Features
Onboard Intel® Celeron® M 600 MHz with 512K L2 Cache CPU
Intel® 82852GM Chipset
Scalable with Avalue EPIC SBC
One SODIMM up to 1 GB DDR SDRAM
Dual View, Optional LVDS I/F
5.1 CH Audio
Dual Intel® 82551ER 10/100Mbps LAN
1 COM, 4 USB 2.0
Specifications
System
CPU Intel® Celeron® M 600 MHz with 512K L2 Cache
BIOS Award
System Chipset Intel® 82852GM GMCH/82801DB ICH4
System Memory One 200-pin SODIMM socket supports up to 1 GB DDR 200/266 SDRAM
SSD One CompactFlash Type I/II socket with ejector
Watchdog Timer Reset: 1 sec.~255 min. and 1 sec. or 1 min./step
H/W Status Monitor Monitoring system temperature, voltage, and cooling fan status. Auto throttling control when CPU overheats
Display Intel® 82852GM GMCH integrated Extreme Graphics 2 controller with 64 MB display memory
Audio AC97 Codec, 5.1 CH Audio
Ethernet Dual Intel® 82551ER 100Base-Tx Ethernet controllers
System Indicators 2 LED indicators show the power and HDD
LAN status shown on the panel
Drive Bay Mounting kit for one 2.5" HDD (hidden)
External I/O
Serial Port 1 x RS-232/422/485
LAN Port 2 x RJ-45
VGA/LCD Port 1 x DB-15, 1 x 26-pin LVDS output (optional)
Audio Port Mic in, Line in, Line out
USB Port 4 x USB 2.0
Parallel Port 1 x DB-25
Mouse & KB 1 x PS/2 mini DIN
Power Input 100 ~ 240 Vdc / 50 ~ 60 Hz
Power Output 12 Vdc / 4.16 A (50W)
Environment & Mechanical
Power Consumption 12V@2.48A
Operating Temperature 0~40°C (32~104°F)
Storage Temperature -20 to 75°C (-4~167°F)
Relative Humidity 5 to 90% @ 40°C (104°F), relative humidity, non-condensing
Dimension (WxDxH) 8.89" x 5.94" x 2.91" (226 mm x 151 mm x 74 mm)
|
|
|
|
|
|
Interactive Kiosk Standard Configuration
• LCD Monitor
Panel size: 19" TFT LCD
Active area: 376.32x301.056(mm2)
Pixel Pitch: 0.294×0.294mm
Resolution: 1280×1024@75HZ
Contrast Ratio: 700:1
Brightness: 250cd/m2
Viewing Angle:H:170° V:170
Displaying Color: 16.7M
Response Time tr/tf: 2/6ms
Band width: 135MHz
Input port: VGA
• Main Board
Chipset: Intel 945G,LGA775,FSB 533/800Mhz
CPU: Dual Core E2160 (1.8GHz)
HDD: SATA 80G,
RAM: 1G DDRII Ram
Wireless LAN: Embedded 54M Wireless Lan with External Antenna
I/O Ports: 1xSerial, 1xUSB, 1xRJ45,
Speakers: Build-in 2x5W Speakers,
• Kiosk
Material: Cold rolled steel ST12 SPCC, 3.0cm thickness
Color: Piano Black Color
Dimension: (H)163.9cm×(W)45.6cm×(Thickness)6cm, Super Slim Kiosk
Bottom Dimension: (H)50.6cm×(W)25cm×(Thickness)0.8cm
Power: 110V-220V Power Supply,
Temperature: +5℃ ~ +35℃;
Humidity: 40% ~ 80%,
• Touch Screen
Vandal-proof, Water and dust proof, Surface Acoustic Wave Touchscreen(SAW)
• Packaging
Both Paper Box and Fumigation Wood Box for Strict Shipping Security
• Warranty
One year panel warranty, 2 Year Parts and Labour Warranty
• Certification
FCC, CE, RoHS
|
|
|
|
|
|
Product Name BOX-PC(R) LP Pentium III 800MHz, DVI, LAN, CardBus, PCI x4
Model Name IPC-BX/M630(PCI)C4P
It is the small computer compatible with IBM PC/AT for industries which carried the Low Voltage Intel Pentium III 800MHz CPU and realized FAN-less operation. You can use broadly various interfaces, such as PCI slot x4, CardBus slot x 1USB, 100BASE-TX and RS-232C/422/485, as an inclusion controller of equipment and a general-purpose personal computer OS base. An indicated price is memory 256MB, HDD, and OS (Windows NT 4.0 or 2000) model.
Features:
Low Voltage Intel(R) Pentium(R) III Processor 800MHz(FSB 133MHz) CPU is carried. FAN-less operation is realized by natural air cooling.
DVI video output loading (VGA conversion adapter appending). PCI slot x 4, CardBus PC card slot, 100BASE-TX LAN, USB,RS-232C/485,AC97 audio standard equipment. Secondary-IDE connector equipment. Connection of option CD-ROM is outside possible.
The its company customize BIOS (product made from Phoenix) is adopted, and support of a BIOS level is possible. At maintenance of the CMOS data based on EEPROM, it can be started also at the time of a battery piece.
Realization of high reliance and the formation of completeness silent (at the time of CONTEC silicon disc PC-SDD V series wearing).
Stable supply (CPU and Chip Set are the Embedded version).
|
|
ASM-CX700
Fanless VIA CX700M Eden V4 Advanced Slim PC
Features
- On Board VIA Eden 500MHz ULV CPU
- VIA CX700M Chipset Support MPEG-4 and WMV9 Video Acceleration
- One SODIMM up to 1 GB DDR2 SDRAM
- 5.1-CH Audio, 1 Mini PCI, 1 Type I/II CF
- 1 COM, 4 USB, 2 SATA, 16 bit GPIO
- Optional DVI output, dual GigaLAN, 2W Amplifier
- 4 LED indicators for Power, HDD, LAN1 & LAN2 (optional)
- Supports 2.5" SATA HDD and USB WIFI module
- Fanless & +12V Operation
- Super Slim Size: 182 x 257 x 25 mm
|
|
|
|
|
|
Ethernet-based visualization
The "VisuNet" visualization platform from Pepperl+Fuchs, based on transfer via Ethernet, now enables significantly simpler and more flexible data transfer over greater distances by means of network technology.
It is available both as a remote solution and as a panel PC. The VisuNet RM Remote Monitor solution comprises in the core an LCD monitor with a network interface. The distance between monitor, keyboard and also the mouse in the Ex area, on the one hand, and the host PC in the safe area on the other, can be up to 70 meters. Via LWL the data transfer range can be increased up to two kilometers. The data transfer from the host PC to the display and also from the keyboard, the mouse and other peripheral equipment, such as a barcode reading device or RFID reader to the PC takes place completely digitally. The "Remote Desktop Protocol" (RDP) is used as the protocol for the data transfer from and to the monitor. Thus a Microsoft protocol is used, which is an integral part of the Microsoft operating systems Windows Vista, Windows XP Professional and Windows 2003 Server.
With VisuNet PC, on the other hand, there is a panel PC with a monitor, keyboard and mouse.
VisuNet is approved in accordance with ATEX, Categories II 2G (Zone 1 Gas) and II 2D (Zone 21 Dust) and is also available in a non-Ex version. The appropriate IEC approval will be available shortly. VisuNet has also an approval according IEC-Standard Zone 1 gas und Zone 21 dust (Touch Sreens: Zone 22 Staub) and furthermore approvals according NEPSI, EOST R and GOSGORTEHNAZOR
|
|
Eurotech offers a range of industrial PC systems in a variety of formats. All units are available with Linux or Windows XP pre-installed on an internal hard drive. Most offer diskless operation using embedded Linux or XP embedded running from Flash memory.
Products
APCx-4 Intel Core 2 Duo 19" rack mount Industrial PC
GEMINI ICE PC Standard 19" 1U enclosure for GEMINI SBC
APOLLO ICE PC Standard 19" 1U enclosure for APOLLO SBC
SBC-GX533 ICE Industrial Compact Enclosure for SBC-GX533 SBC
APC-Industrial PC 19" rackmount industrial PC
|
|
|
Nematron delivers a full range of Industrial PCs in different chassis models. 1U, 2U, 3U, 4U, Shoeboxes standard certified units. 6-slots, 8-slots and 14-slots models are available with UL/cUL certification. Most common CPU's speeds are available and many options can be implemented. Contact sales@nematron.net for more details or send us your specifications and we'll reply with an attractive offer.
|
|
CPC 9000
19"-Rack-PC mit ATX-Mainboard.
Anwendung / Einsatz:
- Industrie-PC für Steuerung und Visualisierung (dezentral, Bedieneinheit abgesetzt)
- Industrie-PC für Mess- und Regelaufgaben, Bildverarbeitung, Steuerungsrechner mit Slot SPS etc.
- Industrie-Server
|
|
|
|
|
|
Eurotech offers a range of CE, EMC and environmentally compliant system enclosures for industrial PC/104, embedded PC and single board computer requirements. The products include traditional rugged 19" rack mount industrial PC chassis systems.
SBC-GX533 ICE
The SBC-GX533 ICE (industrial compact enclosure) is optimised for the SBC-GX533 embedded PC single board computer. The enclosure consists of an aluminium chassis, a 60W AC or 25W 10 - 36V DC power supply cable looms and an optional 2.5" hard drive and integrated safe-shutdown (UPS) module (24V input only). Offering sufficient space to stack two PC/104 expansion modules onto the SBC-GX533 single board computer and provide cable connections from the enclosure. The lid can easily be removed to give good access for development, maintenance and upgrading.
Features
Power supply options:
Universal 90 - 264 AC input (auto-ranging) switched IEC input socket
10 - 36V DC input with screw fitting power input connector
Operating temperature 0°C to 55°C
PS/2 mouse and keyboard socket
VGA outlet (D-type 15 way socket)
4 x serial ports (D-type 9 way plugs)
9 way D-type cutout for additional port
RJ45 Ethernet outlets (10/100 BaseT). LED indication for Rx/Tx and Link
2 x USB channels (1.1 or 2.0 compliant)
Stereo line output via 3.5mm jack
CompactFlash II socket (accessible via removable panel)
25 way D-type cutout for printer port
Expansion space for up to two PC/104 or PC/104-Plus I/O cards
270mm x 256mm x 91mm (W x L x H) including mounting feet
Space for 2.5" IDE hard disk (accessible via removable panel)
|
|
|
|
|
|
Nexcom Introduces VTC 6000 – the new Intel Atom-Based Fan-less in-vehicle PC.
Pioneers in the field of Mobile Computing Solutions Nexcom, have launched an intelligent yet rugged telematics PC, which has been specifically designed for tomorrow’s in-vehicle computing applications. Based on Intel’s energy efficient Atom CPU, the VTC 6000 is fully compliant with most industry standards including the e13 Mark Certification making it suitable for a wide variety of applications within buses, trucks, police cars, taxi cabs and numerous other vehicles.
To facilitate mobile communication and navigation the VTC 6000 has integrated GSM, GPRS, WCDMA, HSDPA and GPS. The unit has a build-in power ignition on/off delay control that enables it to adapt to various power supply conditions within transportation environments. For increased flexibility the VTC 6000 has a 6 – 36V DC power input with an external smart battery backup for uninterrupted power support.
Designed for usage in even the most extreme environments, the VTC 6000 is capable of operation at -30°C to +60°C and can withstand dramatic levels of shock and vibration up to 2G. An optional IP54 enclosure further enhances the systems ruggedness.
For in-vehicle infotainment and digital signage applications the VTC 6000 boasts a multitude of display interface connections such as VGA, TV-out and LVDS. Other features include a PCI-104 expansion slot for CAN or COM expansion and optional Mini PCI express WLAN/3.5G modules.
Typical applications include automated vehicle tracking, driver information systems, in-vehicle signage and vehicle dispatch.
|
|
|
|
|
|
Latest Protech IPC combines multi-serial communications with energy efficient CPU, extended OS support
Extending serial-based communication and energy efficiency to industrial and embedded computing, Protech Systems Co., Ltd., the leading provider of industrial computers, recently released the EPC-8611F system featuring the latest Intel® Celeron® M Ultra-Low Voltage processor with 1 GHz core speed and the Intel® 852GM chipset with Intel® ICH4 I/O hub. Designed to run on Windows® XP/XP Embedded/2000/CE and Linux operating systems, the EPC-8911F supports up to one Gigabyte of system memory using a DDR266 SODIMM and up to six serial ports in customizable RS232 and RS422/485 configurations.
Delivering speeds of up to 115 Kbps for RS232 and up to 921 Kbps for RS422/485 ports, the EPC-8611F brings enhanced connectivity for high-speed data communications. The RS485 port is equipped with an auto-flow control feature that speeds up data transfers and eliminates data over-run or under-run problems.
|
|
Protech's durable POS computer delivers outstanding performance, low power consumption
Advancing the performance of compact form factors, Protech Systems Co., Ltd., the leading industrial PC maker, is pleased to introduce the BPC-8931 low power and high performance POS PC featuring the power-saving VIA C7/ Eden CPU processor and VIA CN700 Northbridge + VT8237R Plus Southbridge chipset. The compact, 3.3 kg BPC-8931 supports higher level systems with up to 2GB of 400/533 DDR2 SDRAM single socket system memory. The high performance, low power BPC-8931 is ideally suited as a POS, kiosk, gaming machine, digital image storage server, or application server. Industrial grade durability ensures long product life and allows the BPC-8931 to be deployed in nearly any environment, from storage server to high traffic kiosk.
|
|
|
|
|
|
Fan-less Industrial PC is Energy Efficient and Cost-Effective.
Nexcom have launched a range of industrial-grade Fan-less Computer Systems based on the energy efficient Intel Atom CPU. Housed in a totally fan-less ruggedized chassis, the NISE 2000 Series offers Industrial Grade Computing at a commercially acceptable price. With long lifetime support, the NISE 2000 series is an excellent choice for embedded vertical markets ranging from industrial automation, machinery, digital signage and kiosk.
The NISE 2000 Series features an on-board 1.6 GHz Intel Atom N270 CPU with 945GSE chipset making the Series both energy-efficient and cost-effective.
To allow a multitude of applications to be considered, the NISE 2000 Series boasts numerous I/O interfaces including two RS232 ports, two RS232/422/485 ports, two GbE LAN ports and four USB/VGA. In addition, the NISE 2000 Series is equipped with one mini-PCIe Socket, and either zero, one or two full-sized PCI slots.
All products in the NISE 2000 Series support up to 2GB of DDR2 memory, with storage via a 2.5” SATA Hard Drive and external CF Socket. The Series unique fan-less design, rugged aluminum chassis and compact dimensions means that the cost-effective NISE 2000 Series is suitable for 24/7 operation in even space-critical applications.
|
|
Compact Industrial PC, PS3000 Series :
- Screens 8.4inch/12.1inch/15inch.
- CPU : Pentium IV/Pentium M/Eden/Celeron.
- Interfaces: COM, USB, Ethernet, CF card, sound.
- HDD or cf card bootable.
- with Win GP: Runtime for PC.
|
|
Individuality is our standard ELMA panel PCs and IPCs are designed and built for automation duties in different sectors and fields,
where computer-aided control units, machinery, plant and processes are controlled. Our portfolio ranges from monitors with keyboards up to complete workstations. All solutions are tailor-made and
– because of their individual designs – are suitable for widely different industries and applications. We pursue a clear objective here: optimization of the human-machine interface.
Operating comfort through good design:
Widely different applications place equally different demands on the design. From individual stainless steel enclosures, through variable front trim and specific paint finishes, we offer everything
needed to meet visual and ergonomic requirements. Our extensive range of accessories includes barcode readers, keyboard shelves and RFID LEGIC® readers. We offer complete solutions from a single source.
|
|
Panel-mounted Industrial PC with TFT graphic display, touch screen
|
|
* Solutions from 5x86 up to Intel Core Duo CPUs
* Fanless embedded designs for best reliability
* Extreme low power consumption
* Extended temperature solutions
* Expansions over PC/104, PC/104-Plus, PMC and PCI
* Long term availability (embedded program)
* For use in medicine, in vehicles, in the industry ...
* Fanless IP65 Panel PC solutions (stainless steel & aluminum)
|
|
The NISE 3110, is the first industrial fan-less computer system of its type to utilize Core 2 Duo and Core Duo Processors. By incorporating the Intel® 945GME Chipset, the NISE 3110 offers users all the advantages of Core Duo technology, such as impressive levels of performance and amazingly low power consumption in a totally Fan-less, noise-free, maintenance-free Industrial computer system.
Support Intel® Core™ 2 Duo /Core™ Duo/ Celeron® M processors
Intel® 945GME Chipsets
Dual 1000/100/10Mbps LAN ports
6 x USB2.0/ VGA / DVI
3 x RS232 and 1 x RS232/422/485 via DB44 Connector
On-board DC to DC power design to support +12V to 30VDC power input
Support ATX power mode and PXE / WOL
One PCI Expansion Slot
Medical grade 120W power adapter
|
|
The SIGMATEK Industrial PCs combine control and visualization tasks. Highest quality and long-term availability of the components are additional important features. Various processor types are available for each model providing scaleable performance that can be adapted to the requirements of the application.
Numerous interface connections, ranging from USB and Ethernet over VARAN and DIAS to CAN are available for communication with the control. A S-DVI connection provides a cost effective connection for control terminals.
Low maintenance and extremely high reliability are strong arguments for choosing IPCs from SIGMATEK.
Compact Flash cards that are addressed as internal drives serve as standardized exchangeable medium instead of the usual hard drives. Applications can therefore be run even in harsh environmental conditions.
|
|
|
|
|
|
Introduction
The IA260 embedded computer comes with 4 RS-232/422/485 serial ports, dual Ethernet ports, 8+8 DI/DO, VGA output, 2 USB hosts, and a CompactFlash socket.
The IA260 computer uses the Cirrus Logic EP9315 ARM9, 32-bit, 200 MHz RISC CPU. This powerful computing engine supports several useful communication functions, but will not generate too much heat. The built-in 32 MB NOR Flash ROM and 128 MB SDRAM give you enough memory to run your application software directly on the IA260.
With its built-in VGA output interface, the IA260 is suitable for use with SCADA systems in industrial applications, such as factory automation, production line process monitoring, and mining automation, that require VGA and HMI features.
The IA260 computer supports RS-232/422/485, digital I/O, and has dual LANs for network redundancy. In addition to the standard model, wide temperature (-40 to 75°C) model is available for use in harsh environments.
The IA260 embedded computers come pre-installed with either Linux or WinCE OS. Software written for a desktop PC can be easily ported to the IA260 platform by using a common compiler, without needing to modify the code, and the software you develop for your own applications can be stored in the IA260's flash memory.
Features
-Cirrus Logic EP9315 ARM9 CPU, 200 MHz
-128 MB RAM on-board, 32 MB flash disk
-4 software-selectable RS-232/422/485 serial ports
-VGA interface for field site monitoring
-Dual 10/100 Mbps Ethernet for network redundancy
-8 8 DI/DO channels, up to 30 VDC
-12 to 48 VDC power input design
-Supports CompactFlash and USB 2.0 hosts
-Ready-to-run Linux/WinCE 6.0 platform
|
|
|
|
|
|
VersaView non-display industrial computers provide the functionality needed to run factory operations from small visual interface and maintenance applications to large control and information applications.
Pairing a powerful VersaView non-display computer with a VersaView monitor produces a workstation capable of directing machines and processes, displaying maintenance information, controlling non-critical processes using SoftLogix™, and serving production information for use in decision-making.
All variations of the VersaView non-display industrial computers offer modern computer technology in industrially hardened cases. With a variety of mounting options available, you can mount a VersaView non-display industrial computer almost anywhere in the plant.
Like all VersaView computers, the non-display computers support multiple communications. All units come standard with Ethernet and serial ports.
VersaView is expanding its portfolio to now include a new line of light industrial non-display computers for less demanding environments where endurance to high temperature, shock and vibration is not as critical.
|
|
|
The rugged iX104 line of Tablet PC's are completely self-contained mobile computers built for the most challenging mobile applications. Designed and 3rd party tested/verfified based on military standards (MIL-STD-810F) they are ideally suited for environments where extreme operating temperatures exist, drops and shock occurs, and dust and moisture are present.
|
|
|
|
|
|
Embedded Line panel PCs combine the best of both worlds: great computing power as well as robust construction and long-life electronics. EL panel PCs are designed for building into control cabinets, the casing of machinery or other forms of mounting apertures and are equipped with bolts and clamping screws on the rear face, to ensure simplicity of assembly and assured sealing (IP65), even in aggressive industrial environments.
EL 870 - 9700
Compact industrial PC with 2 PCI module card slots and 8.0" to 19" TFT display.
more >>
EL 600 - 9000
Compact industrial PC with module insertion slot (PC 104), 6.4" to 19" TFT display.
more >>
EL 2200 - 9200
Industrie Panel PC mit ISA/PCI und Modul Steckplatz (PC 104), 12,1"- bis 19"- TFT-Display.
more >>
AL 5000
Industrial panel PC with ATX mainboard, 15" TFT display and 6-fold PCI bus slot.
more >>
EL 870 - 9700 TC
Kompakter Industrie-PC als Thin Client Terminal mit 8,0" - bis 19" - TFT-Display.
more >>
MP 800 - 9000 DVI
Displayeinheit für dezentrale IPC-Lösungen (Bedieneinheit abgesetzt vom PC), 8,0"- bis 19"-TFT-Display.
|
|
|
|
