The Arc Machines Model 415 is designed to be a versatile welding automation control and power supply system. The standard Model 415 can be used to weld all alloys that are weldable with the Gas Tungsten Arc Welding process (GTAW, or TIG) using straight polarity DC current. The basic Model 415 features a complete complement of controls, water cooling and gas control necessary to operate all AMI orbital weld heads for in-place field welding tasks ranging from small diameter fusion tube welds to heavy-duty piping and vessels. All welding tasks are performed with the unparalleled level of precision and repeatability that have become a world-wide AMI trademark.
The Arc Machines Model 415 Windows™ based power supply/controller features the absolute latest state-of-the-art technology, from its 400 ampere second-generation solid-state Thompson buck-converter power supply to its color VGA display with touch screen.
The Model 415 is an extremely capable power supply that is very easy to operate. The heart of its flexibility is our emphasis on user-definability. Almost all function ranges and modes can be defined by the user to exactly match the welding head or fixture being used. These features include the ability to add up to 4 optional closed-loop motor servos and 8 optional open-loop motor manipulator controls that make it ideal for work-cell manufacturing environments or for use with custom welding heads having unique functions.
Remote operation of the Model 415 requires a minimum of additional options. Most remote welding modes and controls such as lighting and video controls are included as standard equipment.
|
|
Power Supply Modules
• Range of Fixed or Variable Power Supply Module
• Battery Simulator Module Capable of Sinking or Sourctng Current
• Fixed Supplies Have up to U User Specified Outpi Voltages
• Variable Supplies Can Deliver up to 48V Per Channel With 2A Maximum Current
• VISA and Kernel Support For PXI Environments
• Complies with PXI and CompactPCI Specifications
The 41-720 range of Fixed Power Supply modules provides the user with up to 4 separate voltage outputs isolated from the PXI backplane. Any combination of 3.3V. 5V. 12V or 15V can be specified with a maximum current capability of 4A for the 3.3V option Software provides on/off control and status monitoring for each output.
Programmable Power Supplies provide voltage outputs which are fully adjustable under software control. The 40-735 delivers posilive 10V and the 40-736 delivers negative 10V. both with a maximum current of 1A. The output voltage can either be derived from the PXI chassis supply or from an external source.
The 41-740/741 are dual Programmable Power Supplies and can deliver up to 48V at 2A. They are fed from an external AC mains, or DC 56V supply.
|
|
|
Eaton has an extensive line-up of 24VDC switch mode power supplies to fit almost any application. Available with a variety of features including DIN rail and panel mount, Class 1 Divison 2 ratings, parallel capabilities, and many others. Choose from the basic and inexpensive ELC power supplies, the general purpose & heavy-duty industrial PSG series, or the high current boost (outrush) and feature-rich PSS series.
|
|
|
The EG...-130-... series control units contain a DC-side short-circuit protected power pack, voltage stabiliser and output relay. The control units can be actuated by all 2, 3 and 4-wire sensors with PNP, NPN, No, NC or antivalent functions.
|
|
They may be unglamorous and unobtrusive, but without them it would not be possible to operate an electronic system. Power supplies are essential. They provide the voltage supply for sensors, actuators, controllers and other electrical loads. ifm offers low-cost transformer power supplies but also powerful switched-mode power supplies for different applications.
Transformer power supplies
Transformer power supplies provide a low voltage, normally 24 V DC to supply PLCs, sensors or evaluation electronics. A transformer according to DIN 0551 ensures a safe electrical separation from mains voltage and low voltage. The output voltage can be regulated (± 5%) or smoothed by means of capacitors. The different designs and output powers allow adaptation to diverse operating conditions.
Switched-mode power supplies
Primary switched-mode power supplies are a compact and economical solution to supply sensors, actuators and sensitive electronic components and are gaining more and more acceptance. As opposed to conventional transformer power supplies with regulated output voltage primary switched-mode power supplies need no heavy transformers so that there are fewer iron and copper losses. They are therefore distinguished by a very high degree of efficiency of up to 92 %.
|
|
|
Test laboratories are confronted by a huge range of electrical and electronic products with vastly differing power requirements. Frequency and voltage combinations not available from the mains power outlet. Test samples that cause inadequate supplies to cave-in under load. PS3, from EMC PARTNER, solves these problems instantly. Convert the mains wall plug into a custom AC and DC power supply, changeable at the push of a button to any pre-selected frequency or voltage combination.. PS3 is flexible enough to perform EMC immunity tests for CE mark compliance yet stable and robust enough to drive magnetic field antennas. PS3 can be used for industrial, telecom, transport and a host of other applications. An innovative design incorporating the very latest technology, PS3 gives the right power right when it’s needed.
|
|
Absopulse's modular power systems are comprised of plug-in (Eurocard) converter and rectifier modules, and 19" and 23" shelves including motherboards and power distribution panels. These modular designs allow for easy servicing in the field.
Our modular systems offer:
- Output power up to 5kW per 19" shelf
- Almost any input/output and mechanical configuration
- N+1 redundant operation and hot-swap
- Multiple outputs
- Expandability - as power requirements increase, more modules can be added.
- Reconfiguration option
|
|
|
The MTM Power series PMA19 35 has been designed for the use in 19" racks. Due to the very slim case with only 4 TE, the PMA19 35 require very little space within the complete system. The devices have been designed as universal compact power supplies with input voltage ranges of 85...264 VAC and 80...375 VDC for worldwide application. The switching frequency is 80 kHz and they are equipped an internal fuse at the input. The nominal outputs of 5 V, 12 V, 24 V and 48 V are adjustable. Despite the compact design, the devices fulfill all common safety and EMI standards, are prepared for Class I and have a high efficiency. They are continuous short circuit and overload protected and optionally available with a power fail signal.
|
|
MTM Power GmbH, the specialist for high quality power supplies, offers in its program the 19" Euro Card with up to six different, galvanically isolated outputs with 6 or 8 TE. With the MTM Power Card of the series MPK1, an unexpected variety of possibilities can be created for 19" applications. Approx. 1.000 different power supply variations as
19" plug-in can be realised. As in a construction kit, the 19" power supplies can be individually assembled with the three basic components front plate, PCB and connector as well as the vacuum encapsulated modules of the series PMA, PMAS, PMN, PMG and PML. The MPK1 offers 2 mounting positions for PCB modules with an output power of 5 to 48 W, either with single, dual or triple outputs. The MPK2 has one mounting position for modules with an output power of 50 to 100 W and up to three outputs. With the MTM Power Card, power supply variations can be realised in seconds. If requested, a separate LED for each output can be included on the front plate. All modules with the same input voltage can be combined with each other. As customised power supplies have the same dimensions and pinning, even these can be combined with standard modules.
|
|
Open frame
- 3 or 4 output voltages
- VME bus signalling
- Fan monitoring
Power systems
- From 300 W to 1000 W output power
- (n + 1) redundancy
- Design in 3 U subrack
19"
- AC/DC switched mode power supply
- AC/DC linear control systems
- AC/DC converts
|
|
AC/DC power-supply units
The wide range of AC/DC power-supply systems supplied by
Zentro-Elektrik includes devices with one or several output voltages, switched mode or series-regulated devices, modular power-supply systems, including units with hot-swap features and a large selection of power-supply systems in general.
They can be used in various applications as individual devices or redundant system solution or even as battery chargers and DC UPS units.
|
|
DC – UPS Systems for Safety Relevant Installations
With their modular construction, the latest DC – UPS systems in the GTLB/GTPB series from Zentro Elektrik expand the existing comprehensive range of DC – UPS systems for supplying power to safety relevant installations.
The AC/DC systems in standby parallel mode are designed for outputs
from 250 Watt up to 600 Watt and fitted with batteries at the customer’s request. Additional DC/DC converters can be added to the system if more output voltages are required.
A battery control and monitoring module allows to control the charging current and temperature control of the charge closing voltage.
Over and above this, numerous monitoring and control signals are provided via relays, LED’s or potentiometers. A signal relay, for example,
if the charging voltage fails, to switch off the battery on it reaching the closing discharge voltage, to give advance warning of reaching closing discharge voltage with an additional adjustable threshold or individual limitation of the battery charging current to prolong battery life, and
many more. LED displays and adjustable potentiometers provide for comprehensive signalling and the ability to adjust the maximum charging voltage or the defined point of battery switch-off.
|
|
The 9130 is a fully programmable triple output DC Power Supply delivering 0-30V/0-3A on 2 outputs and 0-5V/0-3A on 1 output. Each output is fully floating and outputs can be adjusted independently or connected in series or parallel to produce higher voltages or currents. The 9130 is ideally suited for applications in Electronic Test, Production and Service, where multiple independent DC supplies are required and bench space is at a premium.
# 3 independent, fully programmable and electrically isolated outputs
# Display & adjust Voltage and Current settings for all 3 channels simultaneously
# Flexible output configuration: Operate in series or parallel tracking mode
# SCPI compatible command set. Communicate via USB interface using the included USB to TTL Serial Converter cable
# RS232 interface cable, converting from RS232 to TTL, is optional (order IT-131)
# OVP (Over Voltage) and OTP (Over Temperature) protection
# Output on/off control
# Excellent stability and regulation
# Very compact foot print (rack mountable 2U x 1/2U)
# Application Software for front panel emulation and simple test sequence generation included
# 50 memory locations for instrument state storage & recall
|
|
Our Power Supply with single to 4 channels and digital/analogue display series. Its high stability and enhanced linearity makes this regulated DC power supply significantly useful in where high performance and stable power sources are required. It is widely adopted for R&D, educational and industrial usage.
General Features:
- Single to 4 adjustable channels
- 0-30V voltage linearly adjustment
- 2 display for voltage and current
- Low noise and ripple (<1mV)
- voltage and current pre-set feature
- CV/CC mode auto change
- Full LOADING continuous operation over 16 Hrs
- Conforms to EN61010-1
|
|
Bench Top power supplies are recommended for research and laboratory use. They offer flexibility in terms of voltage range and output polarity. These are stand-alone units which all feature an output voltage display.
The PM20D and PM30D dual output supplies include a 4 digit LCD read out and low voltage (+-5V and +-12V) supplies. Lower cost versions, PM20S and PM30S offering only single polarity output are also available. All supplies in this range accept ac or dc input - referred to as universal supply input.
features :
- mains input
- output range up to 3000V
- low ripple
- positive or negative HV
- overload protected
- clear display of output voltage
- multi-turn set dial
|
|
DC – UPS Systems for Safety Relevant Installations
With their modular construction, the latest DC – UPS systems in the GTLB/GTPB series from Zentro Elektrik expand the existing comprehensive range of DC – UPS systems for supplying power to safety relevant installations.
The AC/DC systems in standby parallel mode are designed for outputs
from 250 Watt up to 600 Watt and fitted with batteries at the customer’s request. Additional DC/DC converters can be added to the system if more output voltages are required.
A battery control and monitoring module allows to control the charging current and temperature control of the charge closing voltage.
Over and above this, numerous monitoring and control signals are provided via relays, LED’s or potentiometers. A signal relay, for example,
if the charging voltage fails, to switch off the battery on it reaching the closing discharge voltage, to give advance warning of reaching closing discharge voltage with an additional adjustable threshold or individual limitation of the battery charging current to prolong battery life, and
many more. LED displays and adjustable potentiometers provide for comprehensive signalling and the ability to adjust the maximum charging voltage or the defined point of battery switch-off.
|
|
AC / DC Power Supplies
Encapsulated Power Modules
We offer the widest range of fully encapsulated AC/DC power modules in the market. There are 4 product series with more than 300 standard models from 6 to 60W for PCB-mounting, with screw terminal block ,with Faston-tabs or for DIN-rail mounting. These power supplies feature universal input 85-264VAC and are available as safety class l or class ll product. The TMT series complies also with medical safety standard IEC/UL 60601-1 and withindustrial safety standard UL508.
|
|
A wide range of power supplies for nearly every requirement.
- Powers from 80W to 12kW
- Currents from 0,4A to 300A
- Voltages from 18V to 300V (or even higher, by request)
- 19" and desktop models with 2/3/6/9HE
- Custom designs possible
- Programmable via analogue interface, USB, IEEE, RS232 or CAN
- Exchangable interface cards with LabView support
- Special version ZH with active load (2400W peak pulse power) and high voltage dynamics, as well as triggerable car start curve according DIN 40839
|
|
# Models 1785B, 1786B, 1787B & 1788 are Programmable DC Power Supplies that offer new levels of "ease of use" and programmable functionality. Direct key in entry makes voltage and current selection fast, accurate and easy. In case calibration allows for simple, cost savings, uninterrupted operation. Sixteen user programmable preset outputs
# Controllable Output On/Off Switch
# 10mV/10mA setability resolution
# Closed case calibration
# Low ripple and noise
# Excellent temperature stability
# Serial interface cable and software included
|
|
High Voltage Power Supplies - rugged, compact, reliable instruments for just about any high voltage application.
With up to 20 kV output capability, a GPIB computer interface, and 0.001 % voltage regulation, these high voltage power supplies have become the industry standard.
There are several models to choose from, with outputs ranging from 1.25 kV to 20 kV.
|
|
# BK Precision's new Model 1761 Triple Output DC Power Supply offers outputs with two 0 to 35V, 0 to 3A and one 2 to 6.5V, 5A outputs with two 4 digit LED displays. The 4 digit LED displays offer 10mV and 1mA resolution which provides higher accuracy. This makes it an ideal supply for power sensitive applications. The 1761 is fully overload protected and comes with a two year warranty. Continuously monitor voltage and current output on two 4-digit LED displays
# Connect two supplies in parallel to double the current output
# Connect two supplies in series to double the voltage output
# Reliable, Durable
# Operate continuously at full load without overheating
# Fully overload protected
# Coarse and fine voltage controls
# Excellent regulation
# Very low ripple
# Constant voltage or constant current operation
|
|
Compact and powerful laboratory power supplies for applications in R&D, schools, workshops and test environments. With analogue interface, current/voltage seperately adjustable from 0...max.
- Voltages from 16V to 150V
- Currents from 2,5A to 40A
- Powers from 80W to 640W
- Analogue interface
- Illuminated LCD or LED displays
- Additional outputs
- Parallel or series connection
- High stability
- Linear and switched mode versions (with wide range input)
|
|
Laboratory Power Supplies
Switched mode or linear laboratory power supplies and interfaces with
IEEE4882 (GPIB), USB1.1, RS232, RS485, CANopen fibre-optic cable
(on request) supplied by Zentro-Elektrik are supplied to customers engaged in research, development and testing, who require individual
and reliable test functions.
Controlled automatically from an external computer or by means of an integrated control unit, they are adjustable either manually or via an analogue interface.
The range of products supplied by Zentro-Elektrik includes such items as equipment for burn-in tests and various applications for use in the lab and testing station.
|
|
The models 1790 is a cost effective, high power, regulated DC power supply with 640 Watt output (0 to 32V, 0 to 20A). It is a linear high current DC power supply suitable for bench operation or standard 19" rack operation. This linear power supply is a high power workhorse that will easily deliver clean power to your high current circuits.
Constant Voltage/Constant Current Operation
Remote Programming Facility
Facility for Presetting the Output Voltage and Max.
Load Current Limits
Separate DC Output ON/OFF Switch
Remote Sensing Facility
High Stability and Close Regulation ±0.01%
Meet CE Specifications
|
|
|
The product family PMN/PCMN with low voltage input completes the range of primary switched MTM Power Modules. The modules offer input ranges of either 20/30...60 VAC or 18/30...72 VDC and allow - due to the different types available in this series - efficient solutions in numerous application fields. The vacuum encapsulated devices offer an isolation of 3,3 kVrms and comply to the up-to-date EN standards as regards CE conformity. Further features are rugged design, SMD-technology, automatic 100 % final test and 100-%-burn-in-test. The series PMN/PCMN offers 10 and 30 W constant output power, is short circuit protected, needs no ground load and is designed for PCB-mounting (PMN) or chassis mounting (PCMN).
|
|
|
Following the state-of-the-art trend in automation for decentralized systems without cabinets MTM Power has designed the new series PM-IP67A with 50, 75, 100, 150 and 200 W. Remarkable feature of the primary switched modules is that they are suitable for applications with protection degree IP67 for different tasks in indoor and outdoor industrial applications. Without any additional protection against harsh environmental conditions these power supplies can be mounted and used just at the place where needed. The compact power supplies with AC and DC wide input range are designed for worldwide use and are available with single and dual outputs of 5, 12, 15, 24, 36, 48, ±12, ±24, ±36, ±48 and 12/24 VDC. Their dimensions are 166,0 x 85,0 x 35,0 mm and they are connected via 7/8" connectors. The devices are vacuum encapsulated, acc. to Protection Class 2 and comply with the Low Voltage Directives as well as with the up-to-date EMC Standards as regards CE Conformity. Further features are rugged design, SMD-technology, automatic 100 % final test and 100-%-burn-in-test. The series PM-IP67A is short circuit protected, needs no ground load and is operating within a temperature range of -40 to 75 °C.
|
|
The TEX-120 series is a range of sealed fieldpower supplies for applications in
harsh outdoor environment. The die-cast aluminium case is water-(incl. salt water), ice, dust and oil resistant to IP67 and NEMA4X requirements.
The construction is shock and vibration proof.The operating temperature range
is specified from -40°C to +85°C without any derating.
There are 2 models available with regulated 12VDC/8A and with 24VDC/5A output. The power supplies feature universal 90 to 264Vac input range and
have safety approvals including CB scheme, IEC/UL 60950-1 and UL 508.
The product is also certified to ATEX94/9/EC for class l, zone ll applications in
hazardous locations.
|
|
Aimtec continues to build its AC-DC product offering with the release of AMEx15-MAZ family of switching power supplies.
In a choice of 3 package types (encapsulated: AME15-MAZ, enclosed screw terminal: AMES15-MAZ and enclosed connector package: AMEC15-MAZ with optional DIN rail bracket for both enclosed packages) with universal inputs of 90~260VAC, 47~440Hz or 120~370VDC the AMEx15-MAZ family offers the unique combination of high I/O isolation of 4000VAC within an wide industrial operating temperature range of -40°C to +85°C. The models in each of the 3 series, AME15-MAZ, AMES15-MAZ and AMEC15-MAZ operate within specifications at temperatures as low as -40°C, which is essential for ensuring reliable product performance in the extreme weather conditions associated with outdoor applications.
Highly regulated, protected, isolated single and dual output ranges of 3.3 – 24 VDC with ripple and noise as low as 50 mV p-p make, tight line and load regulation of ±0.5% (no minimum load required), make the AMEx15-MAZ family ideal for a multitude of applications, including industrial control devices, test and measurement equipment, telecommunications applications and consumer electronics products.
The high-grade galvanic isolation between input and output, in conjunction with internal circuit protections allow these power supplies to be configured for reverse polarity on the output; can be wired in series to create higher output voltages. The 4000VAC isolation protects the application from higher surges on the AC line voltage than standard power supply with just 3000VAC
|
|
Aimtec raises the bar for AC-DC power supplies with the release of AMEL5-MAZ series of switching power supplies.
With universal inputs of 90~260VAC, 47~440Hz or 120~370VDC, within a low profile (51.5 x 26.1 x 15.8mm) PCB mountable encapsulated package, the AMEL5-MAZ stands alone in AC-DC converter marketplace with its high I/O isolation of 4000VAC within a wide industrial operating temperature range of -40°C to +80°C. All 8 models in this series operate to specifications at temperatures as low as -40°C, which is essential for ensuring reliable product performance in the extreme weather conditions associated with outdoor applications.
Highly regulated, protected, isolated single and dual output ranges of 3.3 – 24 VDC with ripple and noise as low as 50 mV p-p make, tight line and load regulation of ±0.5% (no minimum load required), make the AMEL5-MAZ series well suited for a wide variety of applications, including industrial control devices, test and measurement equipment, telecommunications applications and consumer electronics products.
No-load power consumption of only 0.3 watt, and efficiency rates up to 75%, these versatile power supplies meet or exceed the requirements for Energy Star EPS v2.0.
With safety approvals cULus and CB and CE marks, the AMEL5-MAZ series meets the exacting safety standards of EN60601-1-2, EN55011 class B, IEC/EN 61000-3-2, -3-2, and IEC 61000-4-2, -4-1, -4-5, -4-6, -4-8, -4-11, for easy integration in a wide range of controlled, non-life support medical and dental devices, instruments, and equipment applications.
.
|
|
The model 9124 is a laboratory grade, 0-72V/0-1.2A programmable DC Power Supply providing great performance and features not found in other supplies in this price category. The power supply was designed to meet the needs of today’s applications in R&D design verification, production testing or university labs that require clean and reliable power, high resolution/accuracy and fast transient response time.
* Excellent display resolution
* Fast transient response time (<20ms)
* SCPI compatible
* RS232 interface (standard), USB optional
* Closed case calibration
* Compact size for bench use or rack mountable (2U x 1/2U size)
* DVM and Miliohm meter
* Discrete Fault Indicator/Remote Inhibit (DFI/RI). Useful for turning multiple power supplies On/Off simultaneously
* Application Software for front panel emulation and simple test sequence generation included
|
|
|
|
