Isolation transformer USTE seriescast resinsingle-phasefloor-standing
Add to favorites
Compare this product
Characteristics
- Type
- isolation
- Configuration
- cast resin
- Electrical characteristics
- single-phase
- Mounting
- floor-standing
- Other characteristics
- safety, control, vacuum impregnation, compact
- Electric power
Min.: 0.1 W
Max.: 3.2 W
- Primary voltage
Min.: 208 V
Max.: 600 V
- Secondary voltage
Min.: 24 V
Max.: 230 V
Description
General Data
Rated input voltage 208 ‑ 600 Vac
Rated output voltage 24 ‑ 230 Vac
Rated power 100 ‑ 3200 VA
Insulation class B
Maximum ambient temperature 40 °C
Efficiency up to 96 %
Degree of protection IP 00
Advantages
Universal input voltages 208 to 600 Vac
Very good switch‑on behaviour thanks to reduced starting currents
High performance for the volume thanks to compact design
Very good corrosion protection and low noise thanks to BLOCKIMPEX vacuum impregnation
Quick to cable up thanks to the use of spring‑loaded terminals
Contact protected screw connection terminals complying with UVV BGV A3
Simple mounting thanks to robust metal footplate with oval slots
Up to 250 VA with combination footplate for bolted and rail mounting
