Stainless steel cylinders
{{#each product.specData:i}}
{{name}}: {{value}}
{{#i!=(product.specData.length-1)}}
{{/end}}
{{/each}}
{{{product.idpText}}}
{{#each product.specData:i}}
{{name}}: {{value}}
{{#i!=(product.specData.length-1)}}
{{/end}}
{{/each}}
{{{product.idpText}}}

Stroke : 10 mm - 1,000 mm
Speed: 10 mm/s - 1,000 mm/s
This crimped single and double acting cylinder has a stainless steel barrel and rod, anodized aluminum end-caps, NBR/PU seals and aluminum piston. The brackets may be ...
CAMOZZI AUTOMATION

Stroke : 10 mm - 2,500 mm
Speed: 10 mm/s - 500 mm/s
The Cylinder Series 40 is a high-performance, double-acting cylinder with tie-rods that operate at a pressure of 1-10bar, speeds without load of 10-500mm/sec and temperatures of 0°C and 80°C (dry air ...
CAMOZZI AUTOMATION

Stroke : 10 mm - 2,500 mm
Speed: 10 mm/s - 500 mm/s
... -acting Series 41 cylinder is built with tie-rods, AL end blocks and piston, anodized AL-profile tube, NBR rod - piston - cushion seals, rolled stainless steel AISI 420B piston rod, zinc-plated ...
CAMOZZI AUTOMATION

Stroke : 0 mm - 1,000 mm
Force: 0 N - 253 N
Speed: 0.2 m/s - 2.5 m/s
... smooth round cylinder design. • Bore sizes 10 to 25 mm with strokes up to 500 mm. • Temperature range up to +150° in High temperature • Stainless steel tube and anodised end covers ...
Parker Hannifin France SAS

Stroke : 0 mm - 500 mm
Force: 138 N - 4,418 N
Speed: 0.01 m/s - 0.77 m/s
... installation there are holes through the cylinder body that can be used with through bolts or female threads on both front and rear plates. A wide range of ISO 15552 cylinder mountings are available for ...
Parker Hannifin France SAS

Stroke : 0 µm - 6,000,000 µm
Force: 47 N - 3,010 N
Speed: 0.005 m/s
... and simple traverse / transfer applications. Product Overview The OSP-P with stainless steel sealing band for ultra-low friction is a completely modular designed rodless cylinder. It ...
Parker Hannifin France SAS

Stroke : 0.3 in
... sub-miniature cylinders from Clippard can give an amazing force of 2 pounds at 100 psig. For added usability, there is a 45 degree tapered rod end. The stainless steel tube has a maximum ...
Clippard

Stroke : 1, 0.775, 0.5 in
Details 5/32” Single Acting, Spring Return, Sub-Miniature Cylinders Additional Information Action Spring Return, Air Extend Bore 0.15625 Max PSI 150 PSI Medium Air Mount Plain End Ports 10-32 & 3-56 Power Factor 0.02 Rod Rotating ...
Clippard

Stroke : 0.5 in - 6 in
The spring return, air extend unit has a 0.15625 bore, with a maximum PSI of 150 and a plain-end mount with 10-32 and 3-56 ports. The rotating rod diameter is 0.062, with 0.02 power factor. A 0.5000 stroke with 5oz extended spring ...
Clippard

... there is smooth low friction operation. The standard 303 stainless steel comes with 1-1/8-inch bore cylinders. The adjustable cushions provides superior control for cylinder ...
ARO, Ingersoll Rand

... components have been manufactured of stainless steel. The tie rod construction and the 10 standard mounts made available by the manufacturer make this item even more useful for a various range of applications. ...
ARO, Ingersoll Rand

... walled tubes can withstand denting and the cylinder utilizes washout-proof factory-lubricated grease. This cylinder is available with an extruded barrel in bore sizes of 1-1/2", 2", 2-1/2", 3-1/4" and ...
ARO, Ingersoll Rand

Stroke : 10 mm - 2,800 mm
Force: 483 N - 7,363 N
Diameter: 32, 40, 50, 63, 80, 100, 125 mm Stroke length: 10 ... 2800 mm Force: 483 ... 7363 N Double-acting Position sensing Fixed/adjustable/self-adjusting cushioning Special features: Clean design: ...
Festo

Stroke : 1 mm - 500 mm
Force: 19 N - 1,870 N
This position-sensing, double-acting round cylinder is perfect for a wide range of applications and projects. The item comes with a self-adjusting, fixed or completely adjustable cushioning system, depending on your needs. ...
Festo

Stroke : 1 mm - 50 mm
Force: 24 N - 1,763 N
Diameter: 8, 10, 12, 16, 20, 25 mm (standard) Diameter: 32, 40, 50, 63 mm Stroke length: 1 ... 50 mm Force: 24 ... 1763 N Single-acting, pushing Position sensing Fixed cushioning Mounting flange
Festo

Stroke : 25 mm - 500 mm
1393 ÷ 1394 Stainless steel Series The new 1393-1394 stainless steel ISO 15552 cylinders are designed for corrosion resistance application such as marine, ...

Stroke : 0.011 in - 31.978 in
Torque: 2.3 ft.lb - 140 ft.lb
... and Improved" 3-Position Original Line® cylinder features permanent grease lubrication. Design enhancements have more than doubled the anticipated service life of this non-repairable stainless steel ...
Bimba

Stroke : 0.011 in - 50 in
Torque: 2.3 ft.lb - 140 ft.lb
... track mounting switches • - 303 stainless steel rods are standard • - Dimensionally different from the Original Line® including features of the robust "Z-Line" • - Blue and Improved design doubles ...
Bimba

Stroke : 0.011 in - 50 in
Torque: 2.3 ft.lb - 140 ft.lb
The "Blue and Improved" all stainless steel Original Line® cylinder utilizes permanent FDA approved grease lubrication. Design enhancements have more than doubled the anticipated service ...
Bimba

Stroke : 25 mm - 1,000 mm
Cylinders & Actuators - Anti-Corrosive - Series 431 Double Acting - stainless steel - ISO 6431 - Bore 32 mm to 80 mm - Stroke 25 mm to 1000 mm Features • - High quality anti-corrosion ...

Stroke : 1 mm - 500 mm
Mini-cylinders to ISO 6432 with a chamfered stainless steel barrel. The cylinder head dimensions have been reduced for some sizes so that they can be used where there ...
METAL WORK

Stroke : 1 mm - 500 mm
This version of cylinder is used to keep the parts fixed to the piston rod at an angle and to apply torques within the specified limits. The piston rod of the Two Flat has two opposing longitudinal surfaces; it is ...
METAL WORK

Stroke : 1 mm - 500 mm
... torques within the specified limits. The piston rod in Two-Flat cylinders has two opposing longitudinal surfaces and is mode entirely of stainless steel. The front head of the cylinder ...
METAL WORK

Stroke : 10 mm - 2,000 mm
Force: 482 N - 7,363 N
ISO tie rod double acting stainless steel cylinder, 63mm diameter, 200mm stroke Item: KA/8063/JM/200 •High corrosion and acid resistance •Conforms to ISO 6431, VDMA 24562 and NFE ...

Stroke : 40 mm - 1,300 mm
Force: 41 N - 280 N
... Material Cylinder tube Stainless steel Piston rod Stainless steel Piston Brass, Aluminum Front cover Aluminum, anodized End ...
AVENTICS GmbH

Stroke : 25 mm
Force: 294 N
ISO roundline double acting stainless steel cylinder, 25mm diameter, 25mm stroke ITEM: KM/8026/M/25 •High corrosion and acid resistance •Magnetic piston as standard •Conforms to ISO ...
Norgren

Stroke : 80 mm
Force: 294 N
ISO roundline double acting stainless steel cylinder, 25mm diameter, 80mm stroke ITEM: KM/8026/M/80 •High corrosion and acid resistance •Magnetic piston as standard •Conforms to ISO ...
Norgren

Stroke : 25 mm
Force: 294 N
ISO roundline double acting stainless steel cylinder, 25mm diameter, 25mm stroke ITEM: KM/8025/M/25 •High corrosion and acid resistance •Magnetic piston as standard •Conforms to ISO ...
Norgren

Stroke : 10 mm - 320 mm
Force: 30 N - 295 N
- Stainless Steel AISI 303 rolled rod to reduce friction as much as possible - Rod and piston seals with the highest efficiency and longest durability - Metal piston to resist to extreme ...
Airwork Pneumatic Equipment

Stroke : 16 mm - 25 mm
Force: 18 N - 450 N
... extended MX Series – ISO 6432 ISO 6432 cylinders of MX series are entirely made of stainless steel and with highest quality levels. They are available with bores Ø16, 20 and 25 mm. Heads ...
Airwork Pneumatic Equipment

Stroke : 32 mm - 125 mm
Force: 392 N - 4,492 N
... Epoxy coating of both cylinder's heads to protect them from external agents and to improve cylinder's aesthetics Polyurethane high resistance seals for piston and rod Several sealing options: ...
Airwork Pneumatic Equipment

Stroke : 10 mm - 320 mm
Component Parts and Materials 1 Steel AISI 304 Nut 2 Steel AISI 316 Piston rod 3 Polyurethane Rod seal 4 Steel AISI 304 Front cover 5 Steel AISI 304 Nut 6 Sintered ...

Stroke : 25 mm - 1,000 mm
Component Parts and Materials 1 Stainless steel piston rod AISI 304/316 2 PU Seal 3 Bush in sinterized bronze 4 Stinless steel front cover AISI 304/316 5 PU Seal 6 Stainless ...

Force: 0 N - 2,200 N
ERD low-cost electric cylinder series are the perfect alternative to pneumatic cylinders for automating manual processes. The ERD is an economical electric cylinder and is compatible ...

Stroke : 0 in - 4 in
... capability. The composite even polishes the 303 stainless steel shaft for a better shaft life. And the hard chrome-plated stainless piston rod extends the lifetime of the cylinder. Pancake ...
FABCO-AIR

Stroke : 6 in
... inches and strokes to 6 inches • - Machined from aluminum extrusion • - Lightweight aluminum piston • - High-performance composite rod bearing for reduced wear • - Chrome-plated 303 stainless ...
FABCO-AIR

Stainless Steel Air Cylinders Withstand Harsh Environments and Are Interchangeable With Humphrey Line H Series stainless steel air cylinders ...
FABCO-AIR

Stroke : 200 mm
SR20 VZ stainless steel hydraulic cylinder. Standard eye, both ends. SSH Stainless hydraulic cylinders are, of course, made of highly quality ...
SSH Stainless

Speed: 0 m/s - 0.3 m/s
SR20 LL stainless steel hydraulic cylinder. Standard eye, both ends. SSH Stainless hydraulic cylinders are, of course, made of highly quality stainless ...
SSH Stainless

Stroke : 200 mm
SR20 NN stainless steel hydraulic cylinder. POM bushing, both ends. SSH Stainless hydraulic cylinders are, of course, made of highly quality stainless ...
SSH Stainless

... with high resistance to corrosion 96 h ASTM B117 Guidance systems rod of metal or rings reported Attack stem and steel back Computerized control of the tightening of the cylinder head ...

Stroke : 25 mm - 500 mm
The DE series, which are manufactured by Clamptek, is a pneumatic line cylinder that has a body constructed out of anodized extruded aluminum. Its bore sizes ranges from 32 mm, and up to 100 mm in diameter with strokes ...

... long life. Our pneumatic cylinders are made of aluminium, stainless steel and also surface-treated steel. The piston rods in a standard cylinder are ...

Stroke : 10 mm - 500 mm
Force: 482 N - 7,359 N
Covers: Painted die-cast aluminum Tube: Anodised aluminum Seals: Polyurethane - NBR Guide bush: Sintered bronze Piston Rod: Chromium coated steel Max pressure: 10 bar Operating ...
Cy.Pag. S.p.A.

Stroke : 25 mm - 2,500 mm
Force: 295 N - 18,840 N
Cylinders manufactured according to AFNOR NF E49-001 (ex CNOMO). Available with magnet from ø25 to ø200 and without ø32 to ø100, single or through piston rod. Wide range of mounting accessories.
Cy.Pag. S.p.A.

Stroke : 10 mm - 300 mm
Force: 482 N - 754 N
Covers: AISI304 stainless steel Tube: AISI304 stainless steel Piston: aluminium Seals: Polyurethane - NBR Guide bush: sintered bronze Pist rod: Stainless ...
Cy.Pag. S.p.A.

Micro cylinders are available in 2 variants, U type and S type. U type is ISO 6432 compliant with front or rear mounting. S type are front fixing only and therefore are non ISO standard. The stainless ...

Stroke : 10 mm - 500 mm
Available in bores Ø 8-10-12-16-20-25. Execution for high temperature on request. Models with or without cushioning. Extremely resistant thanks to the double rolling assembly procedure.
ARTEC SRL

Stroke : 50 mm - 200 mm
Force: 127 kN - 982 kN
... Manufactured in stainless steel with hard chromated piston. • Collar mounting threads as standard. Models in range CFS350 – CSF860 are equipped with carrying handles on the cylinder ...

Stroke : 16 mm - 25 mm
The ISO 6432 INOX mini-cylinders are particularly recommended for applications In working environments where there is contact with ag- gressive or corrosive agents, which require the use of high-resistance materials. The ...
