Tabletop power supply AX080710

AC/DCIP67emergency

This AC/DC power supply provides clean 24 VDC power suitable for instrumentation and control networks on vehicles. Its IP67 rating, use of a corrosion resistant enclosure, and protection against vibration allows for its use in the most harsh and demanding conditions. It has wide ranging operation from 95-260 VAC, 45/65 Hz, and have high efficiency ratings. Specifications Input(s) 120/208/240 VAC Nominal (95-260 VAC) Enable Not Provided Output(s) 24 VDC +/- 3% (360 W) Output Current 15 A Continuous Isolation 3.75k VAC Enclosure ACD12 Die Cast Aluminum Enclosure and Lid, Hard Anodized to MIL-A-8625 Molded EPDM Gasket 8.14 x 11.10 x 2.75 inches L x W x H including integral connectors Connection(s) 1 8-pin connector equivalent to the TE Deutsch P/N: DT13-08P Heyco 3213 sealed cable gland Integral 3 ft. unterminated power cable (the power plug is not supplied) Operating Temperature -40 to 70 °C -40 to 158 °F Applications Off-highway Vehicles Electric Vehicles Emergency Vehicles Fleet and Utility Vehicles Lift Equipment Mining Equipment
