3-roll calendering machine

3-rollerelectric

Short description
For the calibration and cooling of foamed and compact PVC sheet and board. Polishing units are available for widths from 1,400 mm to 2,200 mm. The polishing units can be adapted to customer requirements and the application and are available either as single components or as part of a complete line.

Your Advantages

• Roll stack for sheet thickness from 0.8 mm to 30 mm
• Electrical gap adjustment with "full-touch" control
• Polishing roll surface temperature control with an accuracy of +/- 0.5°C
• Constant line speeds from 0.1 to 10 m/min

Our Offer

• 3 vertical polishing rolls with outer diameters of 400 or 500 mm
• 3 different roll stack widths
• Pre-calibrating polishing roll unit specially adapted to free-foamed sheet

Technical characteristics / specifications

• Application: Calibration and cooling of foamed and compact PVC sheet and board
• Sheet widths available: 1,400 mm to 2,200 mm
• Supported sheet thickness: 0.8 mm to 30 mm
• Roll configuration: 3 vertical polishing rolls
• Polishing roll outer diameters: 400 mm or 500 mm
• Available roll stack widths: 3 different widths (customer/adaptation dependent)
• Pre-calibrating unit option for free-foamed sheet
• Electrical gap adjustment with "full-touch" control
• Polishing roll surface temperature accuracy: +/- 0.5°C
• Line speed range: 0.1 to 10 m/min (constant speeds)
• Delivery: available as single components or integrated as part of a complete extrusion line
