Load-bearing anti-vibration pad TYPE B30

Soft insulation pad without profile, designed specifically for effective insulation when installed on upper floors. GENERAL PRODUCT DESCRIPTION Description insulation pad Soft variant without a profile. Particularly suitable for effective insulation when installing on upper floors. TECHNICAL DATA AND VARIANTS Note Bilz insulation pads can be cut with any circular or band saw. We are happy to supply special sizes on request. The specified maximum load is composed of static and dynamic loading of the machine. The best insulation effect is achieved at approximately 80-90 % of the specified maximum load. Can also be supplied with a profile on one side (designated for example B4-1). The stated coefficient of friction refers to conventional industrial screed. Cutting tolerance is according to DIN 7715/T5, class P3. Load 20-80 N/cm² Height 18 mm Coefficient of friction 0.8
