Reversible vibratory plate BPR 25/40

compacting

Overview
Reversible vibratory plates BPR 25/40: performance class 25 to 40 kN. Operating weights range from 135 to 300 kg (series up to 750 kg). Optional transport wheels facilitate on-site movement. These units are designed for compaction tasks on earthworks, asphalt and block paving.

Fields of application
Compaction is a core requirement in civil engineering to ensure stable foundations. Reversible vibratory plates are widely used on small and medium construction sites. BOMAG provides a selection of models covering a broad spectrum of applications and operating weights.

Key features

• Height-adjustable, low-vibration steering rod for ergonomic operation.
• Robust quick-mount transport wheels available for models up to 300 kg.
• Protective wide-opening hood for engine and component access.
• Vibration and throttle regulation located on the steering rod.
• Highly wear-resistant, powder-coated base plate and fully protected V-belt.
• Automatic shutdown at low oil level (BPR 25/40); automatic decompression on BPR 25/40D.
• 3-2-1 warranty available.

At a glance

• Emission stage: Stage V / CARB P.3
• Weight (example model shown): 135 kg
• Engine output (example): 3.6 kW
• Working width: 400 mm

Standards

• Protective engine covering
• Comfortable control lever
• Low vibration steering rod
• Height-adjustable steering rod
• Steering rod lockable in transport and working position
• Vibration and throttle regulation on the steering rod
• Highly wear-resistant, powder-coated base plate
• Fully protected V-belt
• Recoil starter
• Back-up drive protection
• Automatic shutdown at low oil level (BPR 25/40)
• Automatic decompression (BPR 25/40D)
• 3-2-1 warranty

Options

• Sprinkler system (+13 kg)
• Tool kit
• Special painting
• Plastic mat
• Transport wheels, puncture-proof (+4 kg)
• Service kit
• US Version EPA 4 NRTC (BPR 25/40D)
• TOUGH WARRANTY

Specifications / technical data

• Model / commercial designation: BPR 25/40
• Operating weight (example shown): 135 kg (series approx. 135 to 300 kg)
• Engine output (example): 3.6 kW
• Working width: 400 mm
• Performance class: 25 to 40 kN
• Emission standard: Stage V / CARB P.3
• Base plate: Highly wear-resistant, powder-coated
• Drive protection: Fully protected V-belt and back-up drive protection
• Starter: Recoil starter (automatic decompression on D version)
• Transport: Robust transport wheels available for models up to 300 kg
• Controls: Height-adjustable, low-vibration steering rod; vibration and throttle regulation on the steering rod
• Service / maintenance: Wide-opening hood for engine protection and access
• Warranty: 3-2-1 (available)
