Belt feeder BMF 2500 M

for bulk materialsPLC-controlledautomated

Overview
The BMF 2500 M feeder optimises material delivery to the paver with high throughput, reliable belt transport and flexible belt options. It conveys a full 27 t truck load of crushed rock, sand or asphalt in approximately 35 seconds, reducing cycle time and operating costs. BOMAG offers this model with pre‑installation options and assistance systems for seamless integration on paving sites.

Key features

• High material flow: up to 4,000 t/h; conveyor belt width 1.2 m.
• Chain‑reinforced conveyor belt for long service life and temperature‑independent operation.
• Robust split‑design scrapers and automatic belt cleaning system.
• Operator workplace adjustable: lift platform and swivel seats for improved ergonomics.
• Automatic distance control for uninterrupted paving process.
• Optional quick‑release swivel (slewable) conveyor belt for side or offset feeding.
• Standard conveyor belt sensor to monitor and control material flow.
• Very large material hopper (approx. 15 t) to provide reserves during lorry changes.
• Pre‑installation for loading assistant, automatic steering and telematics (BOMAG TELEMATICS) available.

Fields of application
The BMF 2500 M is designed for road construction and asphalt paving projects where homogeneous, continuous supply of asphalt or aggregates to the paver is required; side feeding is possible with the swivel belt option.

Technical specifications

• Commercial designation: BMF 2500 M
• Emission stage: Stage IIIa (TIER3) or Stage V (TIER4f) depending on configuration
• Capacity: up to 4,000 t/h
• Conveyor belt width: approx. 1.2 m
• Hopper capacity: approx. 15 t
• Machine weight: approx. 21,000–22,000 kg depending on configuration
• Conveyor: chain‑reinforced conveyor belt
• Belt cleaning: robust split scrapers; automatic cleaning system
• Belt versions: BMF 2500 S (short), BMF 2500 M (medium), BMF 2500 S Offset (slewable short)
• Operator environment: adjustable workstation, lift platform, swivel seats, adjustable dashboard, weather protection roof
• Operation aids: automatic distance control, automatic loading assistant, conveyor belt sensor, central lubrication for conveyor belt
• Options: swivel belt (quick‑release), camera system (compatible with swivel belt), FLEXMIX basis, automatic steering systems, telematics (BOMAG TELEMATICS)
• Lighting & safety: LED roof/working lights, halogen lights, beacon, backup alarm
• Maintenance: reduced maintenance points, improved accessibility, original parts and service support
