Soybean shelling machine MHSA

sunflower seedautomaticimpact

Overview
The MHSA huller is engineered for precise, industrial-scale hulling of oats, spelt, soybeans and sunflower seed. It separates husk from kernel with controlled impact to minimize kernel breakage while maintaining consistent throughput.

Key benefits

• High hulling efficiency through rotor alignment and horizontal impact on the impact ring.
• Flexible configuration: available with or without an integrated control system to suit plant automation levels.
• Designed for long service life with robust housing, reinforced lifting device and easy access to wear parts for reduced maintenance time.

Product features

• Rotor and impact ring arrangement for uniform husk removal and low kernel damage.
• Reinforced lifting device with absolute position sensor for reproducible settings.
• Automatic lubrication system to increase uptime.
• Continuous up-and-down motion of the impact ring to maximize the impact zone.
• Level sensors at the outlet to detect product accumulation and protect the machine.
• Easy access to wear parts to shorten maintenance interventions.

Process role and applications
Hulling removes indigestible husk from the kernel; after hulling, groats are separated so only top-quality groats proceed to kilning/processing. The MHSA is intended for integration into grain processing lines including intake/pre-cleaning, cleaning, dehulling, kilning, flaking/milling and bagging/load out.

Applications

• Oat
• Spelt
• Soybean
• Sunflower seed

Technical specifications

• Model: MHSA
• Suitable raw materials: oats, spelt, soybeans, sunflower seed
• Throughput: up to 4000 kg/h (depending on product and operating conditions)
• Versions: with integrated control system or without
• Key components: rotor and impact ring, reinforced lifting device with absolute position sensor, automatic lubrication system, outlet level sensors
• Design focus: high hulling efficiency, minimal kernel breakage, robust construction, easy access to wear parts
