Dry cleaning machine Vega MTVA

automaticfor the food industrycontinuous

Overview
The Vega MTVA is a compact grain cleaner designed for high-capacity cleaning in agricultural and grain-processing plants. It processes from 15 up to 100 t/h and is available as a free-standing unit or for ceiling suspension. Multiple screen sizes and configurations adapt the machine to different grains and applications.

Key benefits

• Wide range of screen areas (6.6–15.6 m²) and machine sizes for scalable throughput.
• Energy savings up to ~50% when combined with the air-recycling gravity separator that returns ~80% of air to the blower.
• Drive positioned outside the sieve box to simplify belt and wear-part replacement, reducing downtime.

Highlight features

• Throughput range: 15–100 metric t/h depending on configuration and product.
• 11 sifting flow patterns and 2–4 output fractions for flexible separation.
• Suitable for wheat, corn, oats, barley, rye and rice.
• Available free-standing or ceiling-suspended to suit plant layout.
• Screen area options from 6.6 to 15.6 m² and multiple screen types.
• Quick-change screen frames accessible from both sides.

Operation and maintenance
The Vega MTVA is engineered for simple servicing and fast changeover of wear parts.

• Screen frames with quick-release clips for rapid screen replacement.
• Access to the screen stack from both sides for faster handling and service.

Sieve cleaners

• Range of sieve-cleaner options: rubber balls for larger screens or smaller plastic cleaners depending on screen size.

Other features

• Optional connection to an air-recycling gravity separator to remove low-density particles and improve finished-product quality.
• Constructed with low-wear materials to handle abrasive grains and support continuous 24/7 operation.

Applications

• Wheat
• Corn
• Oats
• Barley
• Rye
• Rice

Technical specifications

• Model: Vega MTVA
• Manufacturer: Bühler
• Throughput: approx. 15–100 metric t/h (depends on grain and configuration)
• Machine sizes: two sizes available
• Screen area options: 6.6–15.6 m²
• Sifting flow patterns: 11
• Number of fractions: 2–4
• Sieve cleaners: rubber balls or plastic cleaners (selection by screen size)
• Energy/air recycling: air-recycling gravity separator returns ~80% of air to blower; energy savings up to ~50% vs conventional solutions
• Drive position: drive located outside sieve box for easier belt and wear-part changes
• Installation: free-standing or ceiling-suspended
• Design: low-wear materials for abrasive grains to reduce maintenance and enable continuous operation
