Phase angle controller CL-8-36

Phase angle controller - CL-8-36 - CATU
Phase angle controller - CL-8-36 - CATU
Add to favorites
Compare this product
Go to the CATU website for more information

Description

Short description
Bipolar phase-matching controller for 2 - 36 kV.

Application
  • Bipolar controllers detect potential differences between any two points in a high-voltage installation.
  • Primarily used to locate conductors of the same phase (phase matching), they can also be employed for bipolar detection and high-voltage fuse verification.

Characteristics
  • Potential difference indicated by high-luminosity LED.
  • Voltage range: 2 - 36 kV.
  • Maximum operating distance: 2.25 m (with antenna extensions).
  • Two 1.25 m elements with detachable antennas, connected by a flexible high-voltage cable.

Composition
  • 2 elements of 1.25 m with detachable antennas; length 0.62 m when antennas are removed; connecting cable length 1.5 m.
  • Controller in a plastic case measuring 0.95 m x 0.25 m x 0.1 m.

Accessories (optional)
  • Ref. C-92-20: Replacement antenna, length 0.55 m.
  • Ref. CL-8-05: Antenna extension, length 0.55 m.

Reference table
Reference | Dimensions (mm) | Weight (kg) | Voltage
CL-8-36 | 250 x 950 | 1.1 | 2 - 36 kV

Technical specifications
  • Model: CL-8-36
  • Voltage range: 2 - 36 kV
  • Maximum operating distance: 2.25 m (with antenna extensions)
  • Elements: 2 x 1.25 m with detachable antennas (0.62 m disassembled)
  • Connecting cable length: 1.5 m
  • Controller case dimensions: 0.95 m x 0.25 m x 0.1 m
  • Product dimensions (assembled): 250 x 950 mm
  • Weight: 1.1 kg
  • Indicator: high-luminosity LED to signal potential difference
