Inductive proximity sensor CL08-RN2DN1cylindricalM8with switching function
Add to favorites
Compare this product
Characteristics
- Technology
- inductive
- Shape
- cylindrical
- Diameter
- M8
- Output signal
- with switching function, NPN
- Supply voltage
- DC, 24VDC, 12VDC
- Mounting
- non-flush
- Material
- plastic, brass, PVC
- Protection level
- IP67
- Other characteristics
- with LED light, 3-wire
- Measuring range
0.2 cm
(0.08 in)- Process temperature
Max.: 70 °C
(158 °F)Min.: -25 °C
(-13 °F)
Description
Product overview
Key features
Technical specifications
Operating environment
Summary / technical data
- Model: CL08-RN2DN1 (CL08 series)
- Type: standard inductive proximity sensor
- Detection distance: 2 mm
- Housing: M8 cylindrical
- Output: NPN normally open (NO)
- Cable: 2 m moulded cable
- Protection: IP67
Key features
- Specifically designed to detect metallic targets (standard test piece: iron 8×8×1 mm)
- High response frequency: 800 Hz; response time: 625 μs
- Operating temperature range: -25 to +70 °C
- Materials: nickel-plated brass housing, heat-resistant ABS sensing face, PVC cable
- Included accessories: 2 nuts, 1 serrated washer, certificate
Technical specifications
- Output type: NPN NO
- Supply voltage: DC 12–24 V
- Wiring: three-wire DC
- Protection class: IP67
- Connection: moulded cable
- Signal type: switching
- Switching mode: normally open
- Mounting: non-flush
- Current consumption: < 35 mA
- Indicator: red output LED
- Protection circuits: short-circuit protection and surge protection
- Voltage influence: within ±15% of rated voltage, detection distance change within ±1%
- Load current: < 200 mA
- Insulation resistance: > 50 MΩ (measured with DC 500 V megger) between live parts and housing
- Shock resistance: 500 m/s², X/Y/Z directions, 3 times
- Dielectric strength: AC 1000 V 50/60 Hz 1 min between live parts and housing
- Vibration resistance: 10–55 Hz, double amplitude 1.5 mm, X/Y/Z directions, 2 h
- Weight: approx. 31 g
Operating environment
- Ambient temperature: -25 to +70 °C
Summary / technical data
- Series: CL08
- Model: CL08-RN2DN1
- Detection distance: 2 mm
- Housing: M8 cylindrical
- Output: NPN normally open (NO)
- Supply: DC 12–24 V, three-wire
- Protection: IP67
- Cable: 2 m moulded cable
- Response frequency / time: 800 Hz / 625 μs
- Materials: nickel-plated brass housing, heat-resistant ABS face, PVC cable
- Accessories: 2 nuts, 1 serrated washer, certificate
- Operating temperature: -25 to +70 °C
- Weight: approx. 31 g
