Gas radiant heater DSR 10 Premium Edition

electric

Daygas combines efficient, economical, high-quality, and functional products that prioritize innovation and R&D, saving energy in the heating sector for end users. - Power: 9 kW - Fast start-up and thermal effect. - Possibility to operate in 2 stages and 5 stages with remote control. - Thanks to the separator cover, the heated air is directed forward, allowing installation closer to the ceiling. - Stage display and manual control option on the display screen. - Special color options that withstand temperatures up to 1300°C. - Regional temperature control. - Energy saving. - High safety level. Secure gas valve system. - Low energy consumption. - Easy maintenance and installation. - Frost protection. Technical Specifications / Features: - Capacity: 9kW - Gas consumption: NG 0.86m³/h / LPG 0.63kg/h - Dimensions: 270h / 960L / 225w (mm) - Weight: Net 15.50kg / Gross 17.15kg - Operating pressure: 21-55mbar NG / 32-55mbar LPG - Heating area: min 12m² / avg 20m² / max 30m² - Stages: Standard 2 / Plus 5 - Ceramic plates: 6 pcs - Electrical connection: 230-240VAC 50-60Hz +/-15% - Gas connection: G ¾ - Mounting height: 185 – 350cm Special design with high heat capacity, Daygas ceramic stone, effective and economical performance in local heating solutions. - Sun technology. - All metal components are high-temperature resistant and durable. - All electrical components are made of high-temperature resistant, non-flammable silicone cables. Daygas ceramic radiant devices use special Daygas ceramic stones. The radiation wavelength must be in the infrared range. This is because the surface of the ceramic stone is irradiated according to the desired conditions. The selection and quality of the stone are therefore very important. - Remote control - Integration via control panel - Manual control switch - Thermostat-controlled automatic control - Integration into automation system (SCADA control) The variety of control scenarios offered as 5 different alternatives allows the products to be controlled correctly and as desired. The most suitable control scenario is selected by evaluating the on-site use of the devices in our product range and the site conditions. Therefore, control with the right solution scenario facilitates both fuel savings and long-lasting, trouble-free operation. Our devices can be directly integrated into building automation systems (BMS) via the Modbus communication protocol through the RS485 port (internal). If no BMS system is available, the devices can be fully automatically controlled from a single center via an HMI touch panel or a PC. - Device operating sequence on specified days and hours - Operation of heating devices with regional or individual step and modulation control - Display of device error codes in the system to identify faulty devices and keep errors in memory - Functional controls such as immediate, daily, weekly, or monthly monitoring of fuel consumption are advantages of the integrated automation system - 128x64 graphic LCD display - Automatic and manual control - Communication port with computer - Possibility to connect an external temperature sensor - Possibility to control 8 independent zones and a total of 32 devices - 7 days, 24 hours programmable function - Overheat protection mode - Frost protection function - Encrypted protection function With the Daygas digital room thermostat, it saves fuel by reducing the modulation value of the device according to weather conditions when your devices reach the temperature values you have programmed. When the environment reaches the desired temperature, the device switches off automatically. When the temperature drops below the desired temperature, the device automatically switches to the most suitable temperature level for the environment and starts working again. Thanks to the Daygas analog room thermostat, the device switches off automatically when the heat value you set is reached. When the room temperature then drops below the desired temperature, the device automatically switches on at the maximum level and starts working again. In this way, it saves fuel.
