Electric forklift B series
ride-onhandlinghigh-performance

Electric forklift - B series - Doosan Industrial Vehicles - ride-on / handling / high-performance
Electric forklift - B series - Doosan Industrial Vehicles - ride-on / handling / high-performance
Electric forklift - B series - Doosan Industrial Vehicles - ride-on / handling / high-performance - image - 2
Electric forklift - B series - Doosan Industrial Vehicles - ride-on / handling / high-performance - image - 3
Electric forklift - B series - Doosan Industrial Vehicles - ride-on / handling / high-performance - image - 4
Electric forklift - B series - Doosan Industrial Vehicles - ride-on / handling / high-performance - image - 5
Electric forklift - B series - Doosan Industrial Vehicles - ride-on / handling / high-performance - image - 6
Electric forklift - B series - Doosan Industrial Vehicles - ride-on / handling / high-performance - image - 7
Add to favorites
Compare this product

Characteristics

Motor type
electric
Operator
ride-on
Applications
handling
Other characteristics
high-performance
Carrying capacity

4,000 kg, 4,500 kg, 4,990 kg, 5,000 kg
(8,818.5 lb, 9,920.8 lb, 11,001.1 lb, 11,023.1 lb)

Lifting height

Min.: 3,000 mm
(118.11 in)

Max.: 6,050 mm
(238.19 in)

Overall width

1,470 mm
(57.9 in)

Overall length

4,007 mm, 4,037 mm
(157.8 in, 158.9 in)

Load center distance

500 mm
(19.7 in)

Weight without load

7,012 kg, 7,427 kg, 7,734 kg, 7,763 kg
(15,458.8 lb, 16,373.7 lb, 17,050.6 lb, 17,114.5 lb)

Axle loading with maximum load front

9,874 kg, 10,607 kg, 11,415 kg, 11,450 kg
(21,768.4 lb, 23,384.4 lb, 25,165.8 lb, 25,242.9 lb)

Axle loading without load front

3,695 kg, 3,730 kg, 3,735 kg, 3,770 kg
(8,146.1 lb, 8,223.2 lb, 8,234.3 lb, 8,311.4 lb)

Axle loading without load rear

3,282 kg, 3,732 kg, 3,992 kg, 3,998 kg
(7,235.6 lb, 8,227.7 lb, 8,800.9 lb, 8,814.1 lb)

Track width front

1,160 mm, 1,168 mm
(45.7 in, 46 in)

Track width rear

1,111 mm
(43.7 in)

Height of mast when lowered

2,330 mm, 2,340 mm
(91.7 in, 92.1 in)

Free lift

160 mm
(6.3 in)

Overall height with mast raised

4,170 mm, 4,180 mm, 4,205 mm
(164.2 in, 164.6 in, 165.6 in)

Seat height

1,297 mm, 1,303 mm
(51.1 in, 51.3 in)

Length to fork face

2,957 mm, 2,987 mm
(116.4 in, 117.6 in)

Fork carriage width

1,250 mm
(49.2 in)

Ground clearance under mast with load

120 mm, 130 mm
(4.7 in, 5.1 in)

Ground clearance at center of wheelbase with load

160 mm
(6.3 in)

Turning circle radius

877 mm, 879 mm
(34.5 in, 34.6 in)

Minimum distance between centres of rotation

2,620 mm, 2,645 mm
(103.1 in, 104.1 in)

Travel speed

15 km/h
(9.3 mph)

Lifting speed

0.31 m/s, 0.35 m/s, 0.47 m/s
(1.017 ft/s, 1.148 ft/s, 1.542 ft/s)

Lowering speed

0.45 m/s, 0.48 m/s
(1.476 ft/s, 1.575 ft/s)

Rated drawbar pull

16,426 N, 17,338 N

Gradeability

15 %, 16 %, 17 %, 25 %, 26 %

Rated output

20 kW, 28 kW
(27.2 hp, 38.1 hp)

Maximum operating pressure

155 bar
(2,248.1 psi)

Noise level

70 dB

Description

Discover the biggest from our 7-Series Plus electric forklift line-up, delivering unparalleled dependability and reliability. Featuring ergonomic controls for intuitive operation, these forklifts provide high-performance capabilities, operator comfort, easy maintenance, and excellent value for money, resulting in a low total cost of ownership. These models are available with lead-acid or lithium-ion battery options. Features Ergonomics Premium Seat Designed with a low-profile mechanical suspension that significantly reduces vibrations. It helps the operator stay comfortable, no matter how rough the day gets. Fully Adjustable The operator can change the stepless adjustable column and seat to the best position that provides convenience and comfort to fit the individual's preferences. Finger Tip Controls Fast, precise, and infinitely controllable fingertip control make the 7-Series effortless and efficient. Easy and Instinctive Instrument Panel Operators can control the truck’s performance settings during operation simply by navigating the instrument panel. Productivity Hydraulic Lever with Directional Switch The direction switch is located on the lift lever, which makes it easier for the operator to quickly change between forward and backward driving directions. Excellent Visibility The precisely designed overhead guard profile with angled roof bars provides a clear upward view while ensuring ultimate strength for safety.
