Underground junction box CT S3 1600 series
steelGRPfor cables

Underground junction box - CT S3 1600 series - Ebo Systems SAS - steel / GRP / for cables
Underground junction box - CT S3 1600 series - Ebo Systems SAS - steel / GRP / for cables
Underground junction box - CT S3 1600 series - Ebo Systems SAS - steel / GRP / for cables - image - 2
Underground junction box - CT S3 1600 series - Ebo Systems SAS - steel / GRP / for cables - image - 3
Underground junction box - CT S3 1600 series - Ebo Systems SAS - steel / GRP / for cables - image - 4
Underground junction box - CT S3 1600 series - Ebo Systems SAS - steel / GRP / for cables - image - 5
Add to favorites
Compare this product
Go to the Ebo Systems SAS website for more information

Characteristics

Mounting
underground
Material
steel, GRP
Applications
for cables
Length / diameter

Min.: 1,200 mm
(47.2 in)

Max.: 1,300 mm
(51.2 in)

Width

Min.: 1,200 mm
(47.24 in)

Max.: 1,300 mm
(51.18 in)

Depth

1,600 mm
(62.99 in)

Description

Description
Cable junction box KVK/CT S3 1600 in GRP (glass-fibre reinforced polyester) with interlocking crowns and a G.A.C steel frame. Fitted with GRP lids; ladder and fall protection grid included or available. Usable area 1200×1200 mm; standard height 1600 mm (customisable). Available load resistances: 1.5 t (A15), 12.5 t (B125), 25.0 t (C250).

Dimensions
Inner length: 1200 mm
Inner width: 1200 mm
Outer length: 1300 mm
Outer width: 1300 mm

Material & Color
Material: GRP (Glass-fibre Reinforced Polyester)
Color: Concrete grey
RAL: 7023

Resistances available (product variants)
  • CT S3 1600 A15 — Resistance: 1.5 tons
  • CT S3 1600 B125 — Resistance: 12.5 tons
  • CT S3 1600 C250 — Resistance: 25.0 tons

Components & options
  • Interlocking GRP crowns
  • G.A.C steel frame
  • GRP lids
  • Ladder
  • Fall protection grid
  • Retractable ramp
  • Standard height 1600 mm or custom heights

Technical specifications
  • Product type: Cable junction box (KVK / CT S3 1600)
  • Model: CT S3 1600
  • Usable area: 1200 × 1200 mm
  • Inner dimensions (L×W): 1200 × 1200 mm
  • Outer dimensions (L×W): 1300 × 1300 mm
  • Height: 1600 mm (customisable)
  • Material: Glass-fibre Reinforced Polyester (GRP)
  • Frame: G.A.C steel
  • Color / RAL: Concrete grey / RAL 7023
  • Available load resistances: 1.5 t (A15), 12.5 t (B125), 25.0 t (C250)
  • Product variants: CT S3 1600 A15, CT S3 1600 B125, CT S3 1600 C250
