MIG-MAG welding torch ERGOFLOW 400

water-cooledair-cooledgas-cooled

400 automatic torch MIG/MAG

ENGMAR's automatic fume extraction torches are designed to meet the demands of robotic or mechanized welding. They help increase productivity, reduce repetitive movements, and lower the risk of musculoskeletal disorders, while also compensating for the shortage of skilled labor and ensuring continuous production.

With their integrated extraction system, these torches efficiently capture harmful fumes and gases directly at the source, limiting their spread in the work environment. As a result, all operators present in the production area benefit from better health protection and cleaner ambient air.

Automated welding is a way of increasing productivity and reducing repetitive tasks to avoid an increase in
RSI. It also makes it possible to cope with shortages of welders and thus guarantee continuous production.
Whether manual or automatic, welding generates fumes and gases that are hazardous to health. The use of
an automatic extraction torch enables welding fumes to be captured directly at source, avoiding dilution of
harmful particles in the workshop.

Features:

• Power 440 A (gas mixture)
• 500 A (CO2)
• Duty cycle 100%
• Wire diameter : 1,2 - 1,6 mm
• Available in 0° and 45°

Benefits:

• High-performance extraction
• Up to 98% of fumes captured at the point of generation
• Suitable for high-intensity welding
• Precision and consistency in weld quality
• Enhanced protection for all operators present in the workshop

Standards Compliance
EN 21904-1
EN 21904-4
EN 60974
