Strobe beacon USIX series

LED24 Vdcmulti-color

Available in 24VDC and 120VAC Tri or quad-color models 50,000 hours, vibration-resistant LED light source Surface mount PLC compatible Type 4X, IP66 enclosure IP69K compliant UL and cUL Listed for Class I, Division 2, Groups A, B, C and D; Class II, Division 2, Groups F and G; Class III The UniStat® is a LED based, multi-color, single-high status indicator. Using the latest LED technology, this status indicator can produce three colors (Amber, Green and Red) or four colors (Amber, Blue, Green and Red) from a single light source. The UniStat offers a choice of four integrated flash patterns – steady burn, slow flash, strobe flash and SimuStrobe™. SimuStrobe simulates the attention-getting flash rate of a strobe light but with a much more color-rich output. The user can choose a total of 12 possible flash/color combinations in the tri-color models and 16 in the quad-color models. The USIX is protected in a durable polycarbonate housing utilizing 4-3/4-inch knockout conduit openings in the surface mount base. The outer glass globe is protected by a polycarbonate dome guard (included). Each model arrives preassembled and ready to surface mount
