Automatic edge-banding machine tempora F800 60.12 e-motion

for woodfor panelsfor furniture

Overview The tempora F800 60.12 e-motion is a high-performance edgebander designed for fast, flexible processing of both coiled and strip edge materials. The machine focuses on speed, repeatability and ergonomic operation while delivering precision finishing for industrial panel production. Solid machine chassis and optimised aggregate layout ensure stable processing at high speeds.

Key product features

• Premilling with individually controlled diamond cutters for tear-free edges and chip-free glue joints
• e-motion package: motorised units and premium operating comfort for precise, repeatable settings
• Rigid chassis design for consistent performance during continuous industrial operation

Highlights

• Continuous high output suitable for industrial production
• Configurable processing packages (Professional / Performance) to match company requirements
• Robust design with premium components and serviceability
• Multiple specification packages and optional high-tech aggregates
• Precise engineering and user-centric controls for fast job changes

Details and aggregates (summary)

• Format4 storEdge: edge storage system for safe handling of coiled tape (optional support plate)
• Air cushion table: blower 0.75 kW; supporting surface 1050 x 400 mm (extendable to 2000 x 400 mm) for gentle handling of large panels
• smartouch control with e-motion: network-capable colour touchscreen; unlimited user program storage; maintenance plan and odometer; aggregate selection and 0.01 mm fine adjustment; glue temperature with automatic standby
• edgeControl (Bluetooth): wireless thickness measurement for edge and panel to 0.01 mm; Bluetooth transfer to smartouch; automatic sorting and calibration
• Premilling / Edge jointing: two counter-rotating, individually adjustable premilling units with diamond-coated spiral cutters; depth electronically positionable on e-motion models
• Infrared lamp: preheats edge surface before gluing for improved adhesion on cold panels
• Glue applicator: fast heat-up; Teflon-coated pot with tool-free quick change; suitable for EVA and PUR granulates; glue cylinder fine adjustment; approx. 8 minutes to operating temperature
• PUR melting unit (optional): airtight design for extended PUR durability; low consumption and cleaning effort; continuous reservoir for extended runs
• Edging feed & guillotine trimming: supports coiled 0.4–3.0 mm and strip up to 12 mm for workpiece heights up to 60 mm; infrared sensor for material detection; guillotine trimming up to 64 mm; 120 mm automatic feed magazine
• Pressure rollers: adjustable solid pressure roller plus two conical profiling rollers; selectable contact pressure for strip or coiled material; e-motion includes electronically positionable roller unit
• Sawing / end trimming module: two independent saw units with high-frequency motors (~12,000 rpm); linear guides; tilt 0°–15° (manual, pneumatic or electronic depending on configuration)
• Top & bottom trimming: multifunctional units for flush, radius or bevel trimming; two independent high-frequency units with fast setup; e-motion models allow touchscreen adjustment
• Corner rounding (optional): for edges 0.4–3.0 mm and heights up to 60 mm; cast iron construction, linear guides and tungsten carbide cutters
• "Nesting" package (optional): optimises processing of panels with hinge cup holes or acute angles
• Format4 air-motion (advantEdge): patented aggregate for optical zero joint with co-extruded or laser edges; workpiece-controlled activation for homogenised finish, ideal for high-gloss materials

Technical specifications

• Model family: tempora F800 (e-motion configuration available)
• Edge material (coiled): 0.4–3.0 mm
• Edge material (strip): up to 12 mm
• Maximum workpiece/edging height: up to 60 mm
• Automatic feed magazine capacity: 120 mm
• Guillotine trimming capacity: up to 64 mm
• Air cushion table blower motor: 0.75 kW; supporting surface 1050 x 400 mm (expandable to 2000 x 400 mm)
• Glue system heat-up time: approx. 8 minutes
• Glue types: EVA and PUR granulates; PUR melting unit available
• Trimming and sawing motors: high-frequency motors (~12,000 rpm)
• Aggregate position accuracy: fine adjustment to 0.01 mm (via smartouch on e-motion models)
• Control: smartouch colour touchscreen with network connection and user-program storage
