VACUUM PACKAGING MACHINE IN STAINLESS STEEL WITH TROLLEY
Vacuum machine with trolley in stainless steel. With 1 frontal seal bar 400 mm, vacuum pump 20 m3/h. Also available with MAP.
Vacuum packaging machine with front sealing bar and stand on wheels, made of stainless steel (AISI 304), with digital panel and volumetric electronic sensor for the steady control of vacuum. Tank increased with concave bottom and convex cover for a working height of 230 mm in the central part. Vacuum pump 20 m3/h. It ensures a high productivity.
VACUUM MACHINES WITH GAS INJECTION SYSTEM (ATM)
Vacuum machines can be equipped with gas inlet system (ATM).
Each sealing bar is equipped with two nozzles which introduce gases in different quantities, so the machines are suitable for the packaging of one single use for each sealing bar. When ordering, it is possible to request a modification to the gas inlet system so as to be able to pack two bags per bar by entering the same quantity of gas for each package.
MODEL DZ-400-DL
Sealing bar lenght mm. 400
Number of sealing bar 1 front
Useful lenght mm. 420
Useful width mm. 500
Useful height (chamber + lid) mm. 100/230
Vacuum pump 20 mc/h
Supply 220V
Power 1000W
Process cycle about 30 seconds
Machine width mm. 500
Machine depth mm. 700
Machine height mm. 1050
Machine weight Kg. 96
