Liquid ring pump BE-M serieswaterfor winediesel
Add to favorites
Compare this product
Characteristics
- Technology
- liquid ring
- Fluid
- water, for wine
- Operation
- diesel
- Priming
- self-priming
- Mobility
- stationary
- Domain
- industrial, for the food industry, for the wine industry
- Applications
- transfer, filling, suction
- Fluid specification
- for low-viscosity fluids
- Voltage
- 380 V
- Protection level
- standard
- Other characteristics
- high-efficiency
- Flow
Max.: 6,500 l/h
(1,717.11834 us gal/h)Min.: 420 l/h
(110.95226 us gal/h)- Power
Max.: 800 W
(1.09 hp)Min.: 320 W
(0.44 hp)- Length
Max.: 320 mm
(13 in)Min.: 210 mm
(8 in)- Width
120 mm, 150 mm
(4.72 in, 5.91 in)- Height
190 mm, 210 mm
(7.48 in, 8.27 in)- Weight
Max.: 11 kg
(24.25 lb)Min.: 4 kg
(8.82 lb)
Description
This is the self-priming liquid ring pump, with star-shaped impeller, two directions of rotation as standard, and a high-efficiency motor rated to operate in continuous duty. The special hydraulic shape allows the pump to operate even in the presence of air bubbles in the intake liquid. The liquid ring pump achieves suction by simply filling the pump casing through one of the hose connectors. Suction is active in both directions of rotation. The pump can be used to transfer all kinds of clean, everyday liquids, which must not be chemically aggressive or abrasive. Examples include: water, wine, milk, vinegar, low-viscosity oily solutions, fluid neutral detergents, diesel. The viscosity of the liquid must not exceed 4 cps for continuous duty with free delivery, and must not exceed 20 cps for intermittent duty with free delivery and an operator present for supervision.
