Data connector 814 serieselectrical power supplymaleM12
Add to favorites
Compare this product
Characteristics
- Type
- data, electrical power supply
- Connection type
- male
- Size
- M12
- Material
- polyamide
- Protection class
- IP68
- Other characteristics
- panel-mount
- Primary current
12 A
- Voltage
630 V
Description
M12-S Square female panel mount connector, Contacts: 3+PE, unshielded, single wires, IP40, UL
Connector design - Square female panel mount connector
Version - Connector socket straight
Connector locking system - screw
Termination - single wires
Degree of protection - IP40
IP67 with seal, see accessories
Cross-sectional area - 1.38 mm² / AWG 16
Temperature range from/to - -40 °C / 85 °C
Mechanical operation - > 100 Mating cycles
Weight (g) - 27.02
Customs tariff number - 85369010
