Single-phase electric energy meter C15USL

DIN railModbus RTUwith LCD display

Product name
C15USL - Active and reactive energy meter for bidirectional measurement in single-phase systems; modular design occupying 6 DIN modules with LCD display.

Overview
Compact DIN-rail energy meter designed for accurate measurement of both active (kWh) and reactive (kVArh) energy in single-phase installations. Supports bidirectional measurement for import/export monitoring and is intended for distribution panels, sub-metering and energy management applications.

Documentation available

• Data sheet
• User manual
• Communication protocols - Modbus RTU
• Available options
• Technical drawings (DWG and PDF)

Features

• Measurement type: Active and reactive energy
• Measurement direction: Bidirectional (import/export)
• Configuration: Single-phase
• Form factor: Modular, 6 DIN modules
• Display: LCD suitable for single-phase systems
• Communication: Modbus RTU documented

Applications
Energy metering in single-phase installations requiring simultaneous active and reactive energy monitoring and bidirectional measurement (examples: small distributed generation, battery systems, sub-metering, commercial or light industrial distribution boards).

Technical specifications

• Model: C15USL
• Type: Active and reactive energy meter
• Phase: Single-phase
• Modules width: 6 DIN modules
• Display: LCD
• Bidirectional energy measurement: import/export
• Documentation available: data sheet, user manual, communication protocol specification (Modbus RTU), options, technical drawings
