Three-phase electric energy meter C15UNL

DIN railModbus RTUwith built-in communication

Overview
Bidirectional active-reactive energy meter for 3-phase systems supplied as a modular unit occupying 6 DIN modules. LCD display version intended for balanced 3-phase, 4‑wire installations.

Main features

• Bidirectional measurement of active and reactive energy
• Designed for 3-phase, 4‑wire balanced systems
• Modular form factor: occupies 6 DIN modules
• LCD display for clear readings
• Current input: 1TA
• Communication: Modbus RTU

Available downloads (product-related)

• Data sheet
• User manual
• Communication protocols - Modbus RTU
• Options documentation
• Technical drawings (PDF & DWG)

Notes

• Product presented with main photograph and technical drawings (dimensional and wiring diagrams)

Technical specifications

• Model: C15UNL
• Function: Active and reactive energy measurement (bidirectional)
• Phases / Connections: 3-phase, 4‑wire (balanced)
• Form factor: Modular unit occupying 6 DIN modules
• Display: LCD
• Current input: 1TA
• Communication: Modbus RTU
• Documentation: data sheet, user manual, communication protocols, options list, technical drawings (PDF & DWG)
