Wheeled carrier Z08D

Wheeled carrier - Z08D - Greenbrier Europe
Wheeled carrier - Z08D - Greenbrier Europe
Wheeled carrier - Z08D - Greenbrier Europe - image - 2
Add to favorites
Compare this product

Characteristics

Locomotion
wheeled
Load capacity

75.8 t
(83.6 us ton)

Description

Features
  • This four-axle tank wagon is designed for the transportation of petrochemical products.
  • Compliant with the L4BF tank code and applicable RID, NTSN, RGS and EN standards.
  • Equipped with a vapour recovery system.
  • Bogie: LN25 with integrated BFCB brake.


Capabilities
  • Top-dome loading and filling arrangement.
  • Discharge possible on both sides via TODO couplings.
  • Bottom valve operated by a mechanical bilateral operating device.
  • Equipped with one weighing valve for load control.


Parameters
  • Effective volume: 101.5 m³
  • Axle load: 25.4 t / axle
  • Tare weight: 25.8 t
  • Payload: 75.8 t
  • Track gauge: 1,435 mm
  • Loading gauge: W6a
  • Brake shoe: Cosid 804
  • Max. speed at 101.6 t: 100 km/h
  • Max. speed (unloaded): 120 km/h
  • Climate condition: T1
  • Minimum curve radius (Rmin): 80.0 m
  • Test pressure: 4 bar
  • Max. operating pressure: 3 bar
  • Bogie type: LN25 with BFCB integrated brake
