Thermostatic test chamber 8081-HD

lightsolar simulationfor solar panels

Product overview
PV Module Hot‑Spot Endurance Test Chamber providing a near‑natural irradiance concentrated on a defined area for large‑area PV module aging and hot‑spot endurance testing. Configured with 4 lamps; the light source is a core component and considered consumable.

Test standards

• IEC61215-2:2021 MQT 09, MQT 19
• IEC61730-2:2016 MST22

Technical specifications

• Model: 8081-HD
• Brand: HAIDA
• Light source: 4 lamps (imported from Germany)
• Radiation intensity: 800–1200 W/m² (adjustable)
• Wavelength range: 400–1200 nm
• Spectral matching degree: Class B
• Irradiation inhomogeneity: Class B
• Instabilities: Class A
• Radiation area: 2.4 m × 1.4 m (for one PV module with 4 lamps)
• Light source hang system: adjustable aluminum profile main frame; adjustable lamp spacing
• Typical light source to PV module distance after setup: approx. 1.5 m
• Light method: upper illumination for easy module placement

Applications

• Hot‑spot endurance and accelerated aging tests for large‑area PV modules
• R&D laboratories, certification and quality control departments
• Module manufacturers and independent test laboratories

Maintenance and options

• Replacement lamps are consumables; supplier can provide spares and calibration
• Intensity and lamp spacing adjustable; single‑light‑source system can output real‑time signal to collector for monitoring
• Custom configurations and installation services available on request
