Impact testing machine 8082-HD

computer-controlledPC-controllablefor solar cells

Product Description
The Hail Impact Test Machine verifies that PV modules can withstand hailstone impacts by launching calibrated ice balls at controlled velocities across the module surface and recording impact parameters.

Test Standard
IEC61215-2:2021 MQT 17 Hail Test

Product Specifications
Model: 8082-HD
Suitable for sample size: 2.4×1.2 m
X-axis travel: Approx. 2.4 m
Y-axis travel: Approx. 1.2 m
Locating accuracy: ≤1 mm
Impact area: 2.4×1.2 m (suitable for various panel sizes within this range)
Locating control: PC control with automatic locating
Machine material: Aluminum profile structure

Testing velocity system and theory
A. Ice ball passes through an infrared velocity sensor; the sensor measures break time T and computes velocity V = S / T based on flight distance S.
B. Infrared sensor accuracy: ±5%
C. Measured speed range: 0–50 m/s

Ice ball mould specifications
One mould with 6 cavities and two sets covering 25 mm, 35 mm, 45 mm ice balls
One mould with 4 cavities and three sets covering 55 mm, 65 mm, 75 mm ice balls
Mould material: special easy‑release material
Mould process: CNC machining

System Software
Bilingual software (Chinese/English). Displays impact point, impact speed and ice ball diameter. Test data can be saved, queried and printed. Export formats: Word, Excel, PDF, JPG, etc.

Launch device
Power source: air compressor
Air pressure: 6–8 bar
Ice ball single filled manually
Barrel length: approx. 940 mm (interchangeable barrels available)
Guide ways: high‑quality imported guide rails
Drive: imported servo motor with synchronous wheel

Product Advantages

• Cooperation with professional suppliers to ensure component traceability and consistent delivery.
• Market‑aware pricing to offer competitive, cost‑effective solutions.
• Dedicated QC team performing inspections during production and pre‑shipment using AQL standards.
• Professional finish and presentation suitable for laboratory and production environments.

Technical specifications

• Model: 8082-HD
• Suitable sample size: 2.4 × 1.2 m
• X-axis travel: approx. 2.4 m
• Y-axis travel: approx. 1.2 m
• Locating accuracy: ≤ 1 mm
• Impact area: 2.4 × 1.2 m
• Control: PC control with automatic locating
• Velocity measurement: Infrared sensor; accuracy ±5%; range 0–50 m/s
• Ice ball moulds: sets for diameters 25, 35, 45, 55, 65, 75 mm; CNC machined; easy‑release material
• Launch: pneumatic (air compressor), 6–8 bar; manual ice filling; interchangeable barrel (~940 mm)
• Machine frame: aluminum profile structure
• Drive: servo motor with synchronous wheel; imported guide rails
• Software: bilingual (Chinese/English); displays impact point/speed/diameter; data save/query/print; exports Word/Excel/PDF/JPG
