Diesel generator set HSW-480 T6

three-phase60 Hzdirect fuel injection

The rated output of the Model DC16 44A is 469-kW prp and 511-kW standby. Manufactured by SCANIA, this model has a diesel 4-stroke direct injection engine and a turbocharged/aftercooled aspiration. Bore and stroke measures 127x154mm, and the cylinders’ arrangement is 90-degrees (V8). On standby, fuel consumption is 119.2 l/h. At 25-100% PRP it ranges from 27.4 to 109.62 l/h. Total oil capacity ranges from 35 L – 95 L. At full load, lube oil consumption is 0.3 g/kwh. ACEA E3 - E5 are lube oil specifications. Additional features of the DC16 44A model include compression ratio of 16:1, radiator and blowing fan, 24V electrical system, low water level sensor, water separator decanting filter, guards for mobile components, radiator guards and hot guards, and dry air cleaner.
