Light fixture VANYA 80-R2 series

LEDoutdoorIP66

Product description
VANYA 80 R2 is a retrofit LED luminaire designed to renew and improve the efficiency of service station lighting with minimal installation time and reduced operating costs. It adapts to existing SNP2 250W and 1N 250W frames, delivering the required luminous power and optical characteristics to direct the light beam at 90° for homogeneous and adequate illumination. Rearward LED positioning creates shielding which, together with the metal parabolas in the front frame, minimizes glare. The frame is finished with cataphoresis anti-corrosion treatment and the product includes an integrated surge protection device (Surge), extending service life and reducing maintenance costs.

Technical table
Power: 80 W
Luminous flux: 8950 lm
CCT: 4000 K / 5700 K
CRI: CRI 75 / 83
Optics: Symmetrical 90°
Protection: IP66
Light source: 36 Nichia LEDs
Dimensions: 492×492 mm
Supply voltage: 90 – 304 VAC 50/60 Hz
Median useful life (L70): 80,000 h
Ambient temperature range: -40 °C to +60 °C
Storage temperature range: -40 °C to +70 °C
Storage humidity range: 0–95% RH
Weight: 6.3 kg
Surface treatment: Cataphoresis anti-corrosion painting
Color: White
Warranty: 5 Years

Characteristics / technical specifications

• Retrofit solution for service station lighting to replace SNP2 250W and 1N 250W lamps
• Power: 80 W
• Luminous flux: 8950 lm
• CCT options: 4000 K and 5700 K
• CRI options: 75 or 83
• Optical distribution: Symmetrical 90° beam
• Glare minimization via rearward LED positioning and metal parabolas
• Ingress protection: IP66 suitable for harsh environments
• Light source: 36 high-quality Nichia LEDs
• Dimensions: 492 × 492 mm
• Supply voltage range: 90–304 VAC 50/60 Hz
• Median useful life (L70): 80,000 hours
• Operating ambient temperature range: -40 °C to +60 °C
• Storage temperature range: -40 °C to +70 °C
• Storage humidity range: 0–95% RH
• Weight: 6.3 kg
• Surface treatment: Cataphoresis anti-corrosion painting
• Integrated surge protection device (Surge)
• Color: White
• Warranty: 5 years
