LED panel light ALKA 40 series

Product overview
ALKA 40 is an LED canopy luminaire designed to illuminate petrol station forecourts safely and uniformly. Its 44 W power and symmetrical 77° optics deliver adequate, homogeneous lighting while the recessed positioning of the LEDs inside shaped reflectors reduces glare. The frame is treated with cataphoresis anti-corrosion coating and an integrated surge protection device (Surge) extends service life and reduces maintenance costs.

Technical table
Power: 44 W
Luminous flux: 3970 lm
CCT: 4000 K / 5700 K
CRI: 75 / 83
Optics: Symmetrical 77°
Protection: IP66
Light source: 4 LEDs by Nichia
Dimensions: 300×300 mm
Supply voltage: 100–240 VAC 50/60 Hz
Median useful life (L70): 80,000 h
Ambient temperature range: -40 °C to +60 °C
Storage temperature range: -40 °C to +70 °C
Storage humidity range: 0–95% Rh
Weight: 3.3 Kg
Surface treatment: Cataphoresis (anti-corrosion)
Color: White
Warranty: 5 Years
Photobiological risk (EN62471): Exempt group

Features / technical specifications

• Power: 44 W
• Luminous flux: 3970 lm
• CCT options: 4000 K or 5700 K
• CRI: 75 or 83
• Optics: Symmetrical 77° beam
• IP rating: IP66
• Light source: 4 LEDs by Nichia
• Dimensions: 300 × 300 mm
• Supply voltage: 100–240 VAC 50/60 Hz
• Rated life (L70): 80,000 h
• Operating ambient temperature: -40 °C to +60 °C
• Storage temperature: -40 °C to +70 °C
• Storage humidity: 0–95% Rh
• Weight: 3.3 Kg
• Surface treatment: Cataphoresis (anti-corrosion)
• Colour: White
• Integrated surge protection device (Surge)
• Warranty: 5 Years
