Light fixture Vanya 80

LEDoutdoormaintenance

Product overview
VANYA 80 is an LED canopy luminaire designed for petrol stations and forecourts. It delivers 80 W and 8950 lm with a 90° optics to provide focused, homogeneous illumination under canopies. LEDs are set back within the reflectors to reduce glare. The housing features a cataphoresis anti-corrosion finish and an integrated surge protection device (Surge) for extended service life and reduced maintenance costs.

Technical specifications
Power: 80 W
Luminous flux: 8950 lm
CCT: 4000 K / 5700 K
CRI: 75 / 83
Optics: 90° beam angle
Ingress protection: IP66
Light source: 36 Nichia LEDs
Dimensions: 400 × 400 mm
Supply voltage: 90 – 304 VAC, 50/60 Hz
Median useful life (L70): 80,000 hours
Operating ambient temperature: -40 °C to +60 °C
Storage temperature: -40 °C to +70 °C
Storage humidity: 0 – 95% RH
Weight: 5 Kg
Surface treatment: Cataphoresis (anti-corrosion)
Color: White
Integrated surge protection device (Surge)
Warranty: 5 Years
Photobiological risk: Exempt (EN 62471)

Applications
Designed for canopy and forecourt illumination at petrol stations, service areas, covered car parks and other outdoor canopy installations where focused downward light, low glare and high ingress protection are required.

Key features

• 80 W LED luminaire delivering 8950 lm
• 90° optics for concentrated downward illumination
• 36 Nichia LEDs with recessed positioning to minimize glare
• IP66 protection for outdoor canopy environments
• Wide supply voltage range: 90–304 VAC, 50/60 Hz
• Long lifetime: L70 = 80,000 hours
• Operating range: -40 °C to +60 °C
• Cataphoresis anti-corrosion surface treatment
• Integrated surge protection (Surge)
• 5-year warranty
