Cartridge dust collector Blastrac DC 655

pulse-jet backflowcompactself-cleaning

Product description
The Blastrac DC 655 dust collector is a compact, insulated and transportable unit designed for heavy-duty dust extraction. It provides high airflow and is intended for use with large shot blasting and steel blasting machines. The unit is supplied with six M-class cartridge filters and supports an optional H14 HEPA filter kit. Standard dust handling is via a dustbin kit; Longopac® or big bag systems are available as alternatives. Filters are automatically cleaned by an onboard pulse filter cleaning system driven by a high-performance compressor.

Key features

• Flexible dust handling: standard dustbin; optional Longopac® or big bag system.
• Automatic pulse filter cleaning driven by an onboard high-performance compressor.
• Ergonomic lifting point for easy transport.
• Six replaceable M-class cartridge filters; optional H14 HEPA kit.
• On-board air pistol for equipment and filter cleaning.

Technical data
Rated input power: 6.6 kW
Air flow: 3,200 m³/h
Weight (complete product w/o side packed articles): 481 kg
Rated current: 13.7 A
Power source: Corded (mains)
Phases: 3 ph

Additional information
Equipped with six M-class cartridge filters; optional H14 HEPA filter kit available. Dustbin kit included. Compatible with Longopac® or big bag systems. Automatic pulse filter cleaning. On-board air pistol for maintenance and cleaning.

Specifications

• Model: Blastrac DC 655
• Brand: Husqvarna
• Rated input power: 6.6 kW
• Air flow: 3,200 m³/h
• Weight (complete product w/o side packed articles): 481 kg
• Rated current: 13.7 A
• Power source: Corded (mains)
• Phases: 3 ph
• Filtration: Six M-class cartridge filters; optional H14 HEPA filter kit
• Dust handling: Dustbin kit standard; optional Longopac® system or big bag system
• Filter cleaning: Automatic pulse filter cleaning (on-board high-performance compressor)
• Service/maintenance: On-board air pistol for cleaning and six easy-to-replace filters
• Article number: 970 68 52‑01
