Mini-excavator HX17A Z

crawlerTier 3construction

Product overview
The HX17A Z is a true zero tailswing compact excavator engineered for efficient work in confined areas. With an operating weight around 1.7 t and a Kubota D902 Stage V engine, the machine is suited to landscaping, utilities and light civil works. Note: product literature lists a rated power of 12.1 kW and also references a gross power value of 16.5 kW.

Key specification highlights

• Operating weight: 1850 kg (1.7 t)
• Engine model: Kubota D902
• Engine power: 12.1 kW (gross power sometimes quoted as 16.5 kW)
• Bucket capacity: 0.04 m³

Technical details
Max. torque: 54.6 Nm
Engine emissions: Stage V
Max digging depth: 2440 mm

Comfort & controllability

• 5-inch LCD display for machine settings, diagnostics and hydraulic adjustment
• Digital hydraulic flow adjustment for implements as standard
• Proportional fingertip controls for precise attachment operation
• Optional proportional joysticks to improve operability
• RCV (remote control valve) lever added for easier attachment use

Safety

• Automatic safety lock to prevent unintended operation
• Cabin constructed from integrally welded low-stress high-strength steel (ROPS/TOPS)
• Hydraulic accumulator with reservoir enabling safe lowering of boom and arm when machine is off
• Anti-theft system with password-protected ignition; optional GPS tracker (Hi MATE)
• Safety valve on the dozer blade cylinder for secure loading and digging operations

Productivity & options

• Stage V engine architecture reduces need for complex after-treatment devices
• Optional heavy counterweight for increased stability
• Multiple dipper/arm length options to adapt reach
• Optional factory-fitted hydraulic line to operate hydraulic couplers from the cabin
• Hydraulic piping standard for hammer/shear with selectable single or double acting mode
• Extendable tracks and adjustable dozer blade for improved stability and transport

Serviceability

• Hydraulic hoses routed inside the boom for protection
• Cylinder guards for boom, arm and bucket supplied as standard
• Dozer blade cylinder maintenance interface for easier hose replacement
• Optional Hi MATE telematics for remote monitoring and service support

FAQs / Additional notes
Does the HX17A Z comply with European Stage V emissions? Yes; the engine meets Stage V. The operating weight is shown as approximately 1.7 t (1850 kg).

Technical specifications

• Model: HX17A Z
• Operating weight: 1850 kg (1.7 t)
• Engine model: Kubota D902
• Engine power: 12.1 kW (gross power sometimes referenced as 16.5 kW)
• Max torque: 54.6 Nm
• Engine emissions: Stage V
• Bucket capacity: 0.04 m³
• Max digging depth: 2440 mm
• Design: true zero tailswing
