Pallet lift PL-W series

Product overview

• Dual lift points eliminate the need for counterweight.
• Extremely lightweight design for ease of handling.
• Complies with ASME standards.

PL-W series
Wheels allow movement of the unit without a crane.

PL-WL series
Maintenance-free design with no moving parts.

Technical data
i-LIFT NO. | Model No. | Work Load Limit WLL kg(lb.) | Fork Width mm(in.) | Effective Height mm(in.) | Fork Length mm(in.) | Hook Height mm(in.)
2313411 | PL-W101 | 1000 (2200) | 635 (25) | 1219 (48) | 914 (36) | 1524 (60)
2313412 | PL-W201 | 2000 (4400) | 635 (25) | 1219 (48) | 914 (36) | 1575 (62)
2313413 | PL-WL101 | 1000 (2200) | 635 (25) | 1219 (48) | 914 (36) | 1473 (58)
2313414 | PL-WL201 | 2000 (4400) | 635 (25) | 1219 (48) | 914 (36) | 1575 (62)
2313415 | PL-WL301 | 3000 (6600) | 685.8 (27) | 1219 (48) | 914 (36) | 1651 (65)

Notes

• PL-W and PL-WL are provided as series models with differing WLL and dimensions as listed above.

Technical specifications

• Series: PL-W series (also PL-WL series for maintenance-free variant).
• Standards: Complies with ASME standards.
• Features: Dual lift points (no counterweight required); lightweight design for ease of handling; wheels allow movement without crane (PL-W); maintenance-free with no moving parts (PL-WL).
• Available models and key dimensions: 2313411 / PL-W101 — WLL 1000 kg (2200 lb), Fork Width 635 mm (25 in), Effective Height 1219 mm (48 in), Fork Length 914 mm (36 in), Hook Height 1524 mm (60 in).
• 2313412 / PL-W201 — WLL 2000 kg (4400 lb), Fork Width 635 mm (25 in), Effective Height 1219 mm (48 in), Fork Length 914 mm (36 in), Hook Height 1575 mm (62 in).
• 2313413 / PL-WL101 — WLL 1000 kg (2200 lb), Fork Width 635 mm (25 in), Effective Height 1219 mm (48 in), Fork Length 914 mm (36 in), Hook Height 1473 mm (58 in).
• 2313414 / PL-WL201 — WLL 2000 kg (4400 lb), Fork Width 635 mm (25 in), Effective Height 1219 mm (48 in), Fork Length 914 mm (36 in), Hook Height 1575 mm (62 in).
• 2313415 / PL-WL301 — WLL 3000 kg (6600 lb), Fork Width 685.8 mm (27 in), Effective Height 1219 mm (48 in), Fork Length 914 mm (36 in), Hook Height 1651 mm (65 in).
