Hydraulic demolition shears SK210D-11E

for excavators

Overview
Demolition & recycling machine designed for car-dismantling and multi-dismantling applications. Robust hydraulic layout and heavy-duty undercarriage provide suitability for intensive recycling operations.

Key data
Operating weight: 27,500 kg (Car-dismantling); 30,500 kg (Multi-dismantling)
Engine rated power: 127 kW/2,000 min-1 (ISO14396)

Engine
Model: YANMAR 4TN107FTT
Type: Four-stroke, 4 cylinder, water-cooled, direct injection, turbo charged (with intercooler) diesel engine (Stage V-compliant engine)
Fuel tank: 321 L
Displacement: 4,567 ml
Rated power output: 127 kW/2,000 min-1 (ISO14396)

Hydraulic system
Type: Two variable displacement piston pumps + extra pump + pilot pump
Max. discharge flow: 2 x 220 L/min, 1 x 50.6 L/min, 1 x 20 L/min
Hydraulic fuel tank: 140 L tank oil level; 300 L hydraulic system (Multi-dismantling); 270 L hydraulic system (Car-dismantling)

Travel & Drive
Travel shoes: 46 each side
Travel speed: 6.0 / 3.6 km/h
Swing speed: 12.7 min-1
Drawbar pulling force: 200 kN (SAE)
Gradeability: 58% (30°)

Product specifications SK210D-11E

Caractéristiques / spécifications techniques

• Operating weight: 27,500 kg (Car-dismantling)
• Operating weight: 30,500 kg (Multi-dismantling)
• Engine model: YANMAR 4TN107FTT
• Engine type: Four-stroke, 4 cylinder, water-cooled, direct injection, turbo charged (with intercooler), Stage V-compliant
• Displacement: 4,567 ml
• Fuel tank capacity: 321 L
• Rated power: 127 kW / 2,000 min-1 (ISO14396)
• Hydraulic system: Two variable displacement piston pumps + extra pump + pilot pump
• Hydraulic max. discharge flow: 2 x 220 L/min, 1 x 50.6 L/min, 1 x 20 L/min
• Hydraulic tank / system volumes: 140 L tank oil level; 300 L hydraulic system (Multi-dismantling); 270 L hydraulic system (Car-dismantling)
• Travel shoes: 46 each side
• Travel speed: 6.0 / 3.6 km/h
• Swing speed: 12.7 min-1
• Drawbar pulling force: 200 kN (SAE)
• Gradeability: 58% (30°)
