Media preparator MEDIAPREP30

Product overview
MEDIAPREP30 is an automatic culture medium preparator designed for clinical and research laboratories to sterilize, prepare and dispense culture media with reproducible results. The unit integrates PLC control, an intuitive touchscreen interface and programmable sterilization and dispensing sequences to reduce manual handling and contamination risk.

Key features

• 30 L automatic culture medium preparator (MEDIAPREP-30)
• Intuitive touchscreen for program selection and monitoring
• Siemens PLC control for reliable process automation
• High-quality solenoid valves (Italy) and precision pressure sensor (Switzerland)
• Magnetic stirrer bar (Japan) with adjustable speed
• Includes air compressor and built-in micro printer for records
• Compatible with most media dispensers and aseptic addition ports

Operating modes

• Standard mode: Programmable sterilization and dispensing profiles for routine and high-sensitivity media.
• Chocolate agar mode: Two-step procedure enabling additive introduction (e.g., blood) after initial sterilization and controlled reheating.
• Water bath mode: Pre-dissolution and heating of media at 30–80 °C using an integrated water bath arrangement.
• Sterilization mode: Tabletop sterilizer function for small batches of tubes, flasks and glassware.

Performance and operation
The system provides fast, uniform heating/cooling and controlled agitation to minimize thermal stress and preserve media composition. Automatic leak and lid-seal checks are performed before sterilization. Multiple independent temperature and pressure sensors plus over-pressure protection ensure operational safety. Sterilization parameters and process logs can be recorded for traceability.

Process highlights

• Rapid heating with vapor-saturation control to ensure complete sterilization.
• Precise sterilization control using Pt-1000 probe and microprocessor regulation; adjustable magnetic stirring direction and speed.
• Efficient rapid cooling via plate heat exchanger and isolated cooling-water circuit; pressure maintenance to prevent boiling.
• Aseptic dispensing: large auxiliary addition port, automatic sterile processing of dispensing port and low-residual-volume dispensing design.
• Supports logging of sterilization parameters and process status for regulatory compliance.

Safety

• Dual temperature and pressure interlocks with unique lid-lock mechanism.
• Outer cover locks automatically when temperature > 80 °C and pressure > 50 mbar.
• Upper cover auto-lock at temperature > 50 °C and pressure > 50 mbar to prevent accidental opening.
• Over-temperature protection to 130 °C with alarm at +2.5 °C and automatic shutdown on extreme over-temperature.
• Pressure vessel certified to relevant standards.

Technical specifications

• MODEL: MEDIAPREP-12 (HMP-12); MEDIAPREP-30 (HMP-30)
• Inner bucket capacity: 12 L (HMP-12); 30 L (HMP-30)
• Chamber capacity: 18 L (HMP-12); 45 L (HMP-30)
• Chamber size (D × H): 300 mm × 260 mm (HMP-12); 300 mm × 640 mm (HMP-30)
• Inner bucket size (D × H): 260 mm × 222 mm (HMP-12); 260 mm × 600 mm (HMP-30)
• Sterilization temperature: 70 °C – 130 °C (design temp. 140 °C)
• Dispensing temperature: 25 °C – 80 °C
• Water bath temperature: 30 °C – 80 °C
• Max working pressure: 2.5 bar (design pressure: 4 bar)
• Cavity sterilized water: Deionized pure water; auto water supplement (requires supply pressure ≥ 1 bar); high/low water level alarm
• Cooling water ports: 2 points, inner wire, diameter 12 pagoda joint
• Circulating water: tap water, pressure ≥ 1 bar
• Drainage port: 2 points, inner wire, diameter 12 pagoda joint
• Temperature accuracy: 0.1 °C
• Temperature offset: 0.5 °C
• Time setting accuracy: 1 minute
• Sterilization pot material: 1.4301 / 1.4305 (similar to SS316)
• Dispense ports: 2 pcs (adaptable to multiple dispensing assemblies; one suitable for aseptic additions)
• Dispensing hose: ID 6 mm, thickness 2 mm
• Material feeding port diameter: 32 mm
• Stirring: magnetic stirring — HMP-12: 120–240 rpm adjustable; HMP-30: 0–120 rpm adjustable
• Pressure supplement: complementary pressure water cooling to maintain tank pressure during rapid cooling
• Heating power: HMP-12: 3.6 kW; HMP-30: 6.6 kW
• Power supply: HMP-12: AC 220–240 V, 50/60 Hz, 20 A; HMP-30: AC 3P 380–420 V, 50/60 Hz, 32 A
• Dimensions (L × W × H): HMP-12: 550 × 700 × 545 mm; HMP-30: 550 × 700 × 975 mm
• Weight (NW / GW): HMP-12: 111 kg / 160 kg; HMP-30: 135 kg / 175 kg
