Spray nozzle QFYF series

washingfor liquidsfull-cone

Full cone spray. Unibody design allows for secure and easy installation, and X-shaped core provides minimal clogging. It is often used in etching and developing processes for semiconductors and printed circuit boards that require extremely high spray uniformity. Two piece nozzle design which includes nozzle and the body allows quick and accurate installation by hand. It is convenient for on-site management. Nozzle tip is secured into the body and fastened by three buckle points to avoid the nozzle tip loosening and ensure the performance quality. Internal gaskets are available in various options such as EPDM, Viton, and Viton-F, which can be adapted to various types of chemical processes. The special structural design allows the nozzles to closely contact the base to prevent water leakage. Y-shaped rotary handle design leads to easier dismantling. Recommended working pressure: 2.0 kgf/cm² Flowrate tolerance: ± 5% @ 2.0 ± 0.1 kgf/cm² Angle tolerance: ± 5° @ 2.0 ± 0.1 kgf/cm²
