Spray nozzle QFYH series

for liquidsflat spraypolypropylene

The spraying type is fan type, and the spray shape is single line and two sides are tapered (tapered edge), which presents a bell curve shape flow field distribution with weaker ends compared to the middle. Products with special flow field distribution can be customized. Two piece nozzle design which includes nozzle and the body allows quick and accurate installation by hand. It is convenient for on-site management. Nozzle tip is secured into the body and fastened by three buckle points to avoid the nozzle tip loosening and ensure the performance quality. The internal gaskets are available in various options such as EPDM, Viton and Viton-F, which can be adapted to various chemical processes. The special structural design allows the nozzles and the base to fit closely and avoid water leakage. Y-shaped rotary handle design leads to easier dismantling. PVDF is resistant to temperature and corrosive chemical solutions. Recommended working pressure: 3.0 kgf/cm² Flowrate tolerance: ± 5% @ 3.0 ± 0.1kgf/cm² Angle tolerance: ± 5° @ 3.0 ± 0.1kgf/cm²
