Cartridge filter housing CLF-T

for gasPTFE

- Liquid particle filter for the separation of aerosols - High retention rate of 99.99 % for particles > 0.1 μm - High chemical resistance - With double-layer ultrafine special glass-fiber filter element - With filter head made of PTFE - Flow rate: max. 300 Nl/h - Easy change of filter element - With wall-mounting bracket - 2 gas connections: female threaded G 1/4" - Condensate outlet: GL 25 with cap - Material of sample-contacting parts: glass-fiber, PTFE, Viton®, glass The M&C liquid particle filter CLF-... is suitable for filtration of fluid particles of all types and is recommended for sample gases with an acid dew point above 100 °C. Examples are measurements in flue gas of heavy oil and black coal combustions. The filter separates the aerosols (very fine fluid particles) which still pass the gas cooler. The most effective position of the CLF-... filter is downstream the sample conditioning, directly in front of the flow meter of the analyzer. Liquid particle filter type CLF‑T with double‑layer ultra‑fine special glass‑fiber filter element, separation rate: 99.99 % for particles > 0.1 µm, flow rate: max. 300 Nl/h, sample gas temperature: filter head made of PTFE with Viton® O‑ring, filter body made of glass with GL 25 drain, material: PTFE, Viton®, glass
