Sinker electrical discharge machine EDNC8

high-speedCNC

Overview
The EDNC8 is the second machine in the EDNC-Series sinker EDM lineup. It provides larger X/Y/Z strokes and additional processing capacity compared with the EDNC6. The machine is built for reliable high productivity and integrates advanced Makino EDM technologies and a user-friendly control environment.

Control & Productivity Features

• Hyper-i control system with an intuitive graphical interface to streamline operations across operator skill levels.
• Integrated EDM Assist (on-board digital manuals and training system) and advanced E‑Tech Doctor help functions to support operators.
• Makino HyperCut and SuperSpark™ IV technologies to increase cutting efficiency and improve productivity.
• Optional ATC (automatic tool changer) to extend unattended operation while allowing full use of the machine stroke and work tank area.

Performance Options

• HS-Rib Z-axis option: enables high-speed jump motions up to 20 m/min with up to 1.5 G acceleration; includes integral liquid-core cooling of the ballscrew to maintain precision depth control and can reduce machining times by up to 60% (option-dependent).
• Two work tank configurations: standard and wide-tank to accommodate different part sizes and production needs.

Design & Access
The EDNC8 uses a stationary worktable and a space-saving design that enhances thermal stability by integrating the dielectric reservoir into the base casting. The machine provides excellent operator access to the work zone for part setup and viewing of operations.

Technical data table (metric)
Table: 1,100 x 700 mm
X: 800 mm Y: 500 mm Z: 400 mm (500 mm)
Rapid Traverse: 5 m/min
Maximum Workpiece Weight: 3,000 kg
ATC Capacity: 16, 32
Tank Size: 1,400 x 900 x 500 mm
Max Electrode Weight: 100 kg
Max Available Amperage: 60A ~ 240A

Technical data table (english)
Table: 43.3" x 27.6"
X: 31.5" Y: 19.7" Z: 15.8" (19.7")
Rapid Traverse: 197"/min
Maximum Workpiece Weight: 6,614 lbs
ATC Capacity: 16, 32
Tank Size: 55.1" x 35.4" x 19.7"
Max Electrode Weight: 220 lbs
Max Available Amperage: 60A ~ 240A

Notes
The standard EDNC8 supports workpiece sizes up to 55.1" x 35.4" (1,400 mm x 900 mm) with a three-sided programmable rise-and-fall work tank. The wide-tank version supports larger parts up to 70.8" x 47.2" (1,800 mm x 1,200 mm) and uses a programmable rise-and-fall front door. Both configurations use the stationary worktable and integrated dielectric reservoir design to improve thermal stability.
