- MARSVALVEUK
Disc valve leverisolationshut-off
Add to favorites
Compare this product
Characteristics
- Type
- disc
- Operation
- lever
- Function
- shut-off, isolation
- Media
- for liquid food products and beverages, for dairy products
- Body
- wafer, weld, compact
- Applications
- for pharmaceutical applications, sanitary, wafer
- Material
- stainless steel, PTFE, EPDM, silicone
- Other characteristics
- compact, with butt weld ends, with tri-clamp connection
- DN
Max.: 152 mm
(5.984 in)Min.: 25 mm
(0.984 in)- Pressure
Max.: 150 bar
(2,175.6 psi)Min.: 0 bar
(0 psi)- Temperature
Max.: 140 °C
(284 °F)Min.: -10 °C
(14 °F)
Description
Product description
A hygienic sanitary butterfly valve manufactured in 316L stainless steel for food, beverage and pharmaceutical pipeline systems. Compact wafer design for space-saving installation. Available with Tri-Clamp or weld ends, selectable seat materials (EPDM, silicone or PTFE) and an electropolished disc for optimal cleanability.
Main features
Applications
Compliance & maintenance
Ordering information
A hygienic sanitary butterfly valve manufactured in 316L stainless steel for food, beverage and pharmaceutical pipeline systems. Compact wafer design for space-saving installation. Available with Tri-Clamp or weld ends, selectable seat materials (EPDM, silicone or PTFE) and an electropolished disc for optimal cleanability.
Main features
- Body and disc: 316L stainless steel
- Design: wafer (compact) type
- Sizes: 1"–6" (25–152 mm)
- Pressure rating: up to 150 PSI (≈10.3 bar)
- Seat options: EPDM / Silicone / PTFE
- End connections: Tri-Clamp or weld ends
Applications
- Food and beverage processing
- Dairy and brewing lines
- Pharmaceutical and biotech piping
- Hygienic process systems requiring CIP/SIP
Compliance & maintenance
- Electropolished disc and smooth internal surfaces for hygienic operation
- Suitable for CIP/SIP routines; materials compatible with common cleaning agents
- Traceability and material certificates available on request
Ordering information
- Specify size, seat material and end type when ordering
- Custom finishes and special sealing compounds available on request
