Hydraulic press PHE-300formingC-frameautomatic
Add to favorites
Compare this product
Characteristics
- Operation
- hydraulic
- Function
- forming
- Structure
- C-frame
- Control
- automatic
- Other characteristics
- double-action
- Force
50 tf
- Opening
136 mm, 200 mm, 800 mm, 1,000 mm
(5 in, 8 in, 31 in, 39 in)- Stroke
250 mm
(9.843 in)- Max. pressure
315 bar
(4,569 psi)- Working speed
5 mm/s
- Weight
480 kg
(1,058 lb)- Overall width
1,170 mm
(46 in)- Overall height
2,230 mm
(88 in)
Description
The press MECAMAQ type PHE-300, It has a power of 300 Tm, the operation of the top table is by means of 4 cylinders of double effect with guided by means of tips with bronze and system of leveling with gears and toothed zipper, the useful dimensions of the tables between columns are 3000 x 500 mm.
The course of the top table is of 250 mm and the opening between tables 500 mm.
Speed of approximation: 1020 mm x minute and that of work: 240 mm x minute.
The maximum pressure of the hydraulic group is of 290Bars and the power of the engine 15 Hp.
The regulation of courses is by means of ends of stops and that of pressure for electrical switch with automatic investment.
Operation by means of console to two hands and protection by photoelectric barriers.
Features
Engine power (HP) - 7,5
Approximation speed (mm/s) - 35
