Signal calibrator K 800

for strain gauge amplifiersload cellprogrammable

Description
The K 800 calibrators are engineered to reproduce standardized electrical signals that simulate quarter-bridge strain gauge outputs under specified mechanical loads. They provide stable, repeatable signals for calibration, verification and commissioning of strain-gauge measurement chains and load-cell systems.

Features and applications

• Single load-cell simulation (compatible with calibration of AP814 and AP815 in MGCplus)
• Parallel control of up to 8 calibration outputs
• Four resistance ranges: 120 Ω, 350 Ω, 700 Ω, 1000 Ω
• Operation: manual control or PC-controlled
• LED status indication for quick diagnostics
• Intended for calibration, fine tuning and commissioning of multi-channel (up to 8 channels) strain-gauge amplifiers and measurement systems
• Registered in the national/state register of measuring instruments

Technical specifications

• Function: reproduction of standardized electrical signals to simulate quarter-bridge strain gauges
• Load-cell simulation: single load-cell simulation (for calibration of AP814 and AP815 in MGCplus)
• Channels/control: parallel control of up to 8 calibration signals
• Calibration resistance ranges: 120 Ω, 350 Ω, 700 Ω, 1000 Ω
• Operation modes: manual or PC-driven control
• Display: LED status indicators
• Use cases: calibration, tuning and commissioning of multi-channel strain-gauge amplifiers and systems
• Approval: entry in the national/state register of measuring instruments
