Machine foot HMF series

equipmentfor food industry machinerynitrile rubber

Overview
Machine feet HMF equipped with two floor locking plates and a fully-threaded spindle, providing enhanced stability, reduced vibrations and precise height adjustment for industrial, food processing and pharmaceutical environments.

Features & Advantages

• Two floor locking plates for secure anchoring, even load distribution and reduced vibration and wear.
• Fully-threaded spindle enabling accurate height adjustment and secure positioning to prevent unintended shifts during operation.
• Hygienic rounded design and smooth surfaces for easy cleaning and reduced bacteria accumulation.
• Rubber base for vibration damping and anti-slip properties; slope compensation up to 10°.

Design & Materials

• Base plate: Stainless steel AISI 304 or AISI 316.
• Spindle: Stainless steel A2-70 or A4-70.
• Rubber base: NBR (Nitrile) rubber, CAS 9005-98-5; vulcanized rubber base with FDA certificate (FDA CFR 21 177.2600) and unique batch ID for traceability.
• All materials offer high resistance to chemicals, common cleaning agents, oils and fats.

Sizes — HMF Base
HMF Base — Base Diameter D — Nom. Load
HMF 62 — 60mm — 7.000 N
HMF 82 — 80mm — 15.000 N
HMF 102 — 100mm — 20.000 N
HMF 122 — 120mm — 30.000 N

HMF Spindle threads
M12 — M16 — M20 — M24 — M30 — M36 — M42 — M48

HMF Spindle length (L)
50mm — 70mm — 100mm — 120mm — 150mm — 180mm — 200mm — 230mm — 280mm — 330mm

Customization & Delivery

• Inch threads and special thread types (e.g. trapezoidal) available on request.
• For large orders, bases and spindles can be supplied separately to allow flexibility when using multiple spindle sizes.

Applications

• Food processing industry
• Pharmaceutical industry
• Biotechnology and cleanroom applications
• Packaging and heavy-duty industrial equipment requiring stable, hygienic and adjustable supports

Technical specifications

• Product type: Machine feet with 2 floor locking plates and fully-threaded spindle (HMF).
• Hygienic rounded design for easy cleaning.
• FDA certified vulcanized rubber base (FDA CFR 21 177.2600) with batch traceability.
• Base materials: AISI 304 or AISI 316 stainless steel.
• Spindle materials: A2-70 or A4-70 stainless steel.
• Rubber material: NBR (Nitrile rubber), CAS 9005-98-5.
• Nominal loads by base size: HMF 62 = 7.000 N; HMF 82 = 15.000 N; HMF 102 = 20.000 N; HMF 122 = 30.000 N.
• Available spindle threads: M12, M16, M20, M24, M30, M36, M42, M48.
• Available spindle lengths: 50mm, 70mm, 100mm, 120mm, 150mm, 180mm, 200mm, 230mm, 280mm, 330mm.
• Slope compensation: up to 10°.
• High chemical and cleaning-agent resistance.
