Overview
The FEP20-NP, FEP25-NP, FEP30-NP and FEP35-NP are NP Series electric counterbalanced forklifts with rated capacities from 2,000 to 3,500 kg. These models are intended for industrial material handling and internal logistics operations. The product page includes detail images and an embedded product video.

Key specifications

• Series: NP Series Electric Forklift
• Models: FEP20-NP, FEP25-NP, FEP30-NP, FEP35-NP
• Rated capacities: 2,000 / 2,500 / 3,000 / 3,500 kg
• Service weight (including battery): 3,790 / 3,942 / 4,573 / 4,748 kg (by model)
• Free lift: 140 mm (FEP20/FEP25), 145 mm (FEP30/FEP35)
• Load centre distance: 500 mm
• Fork dimensions (s/e/l): 40/122/1070 / 45/122/1070 / 50/122/1070 (varies by model)
• Turning radius: 2,100 mm (FEP20/FEP25), 2,220 mm (FEP30/FEP35)
• Travel speed (laden/unladen): 18 / 19 km/h
• Maximum gradient (laden/unladen): up to 20% / 20% (model-dependent; FEP35: 15%/20% loaded/unloaded)
• Battery options (V / Ah): multiple configurations including 80 V systems with capacities such as 200, 268, 280, 324, 400, 412 and 536 Ah depending on model and configuration
• Motor control: AC / PMSM

Technical data (per model)

• FEP20-NP: Rated load 2,000 kg; Service weight 3,790 kg; Free lift 140 mm; Forks 40/122/1070 mm; Turning radius 2,100 mm; Travel speed 18/19 km/h; Max gradient 20%/20%; Battery options include 80 V with 280/324 Ah and other configurations; Motor control AC/PMSM.
• FEP25-NP: Rated load 2,500 kg; Service weight 3,942 kg; Free lift 140 mm; Forks 40/122/1070 mm; Turning radius 2,100 mm; Travel speed 18/19 km/h; Max gradient 20%/20%; Battery options include 80 V with 280/324/412 Ah and other configurations; Motor control AC/PMSM.
• FEP30-NP: Rated load 3,000 kg; Service weight 4,573 kg; Free lift 145 mm; Forks 45/122/1070 mm; Turning radius 2,220 mm; Travel speed 18/19 km/h; Max gradient 20%/20%; Battery options include 80 V with 280/324/412 and configurations with 80 V / 200/268/400/536 Ah; Motor control AC/PMSM.
• FEP35-NP: Rated load 3,500 kg; Service weight 4,748 kg; Free lift 145 mm; Forks 50/122/1070 mm; Turning radius 2,220 mm; Travel speed 18/19 km/h; Max gradient 15%/20% (laden/unladen); Battery options similar to FEP30-NP with multiple 80 V capacities; Motor control AC/PMSM.

Applications

• Internal logistics and warehouse handling
• Production and assembly line material supply
• Loading/unloading in distribution centers and yards
• Industrial sites requiring electric counterbalanced trucks

Additional information
The product page provides multiple detail images showing exterior and component views and an embedded product video. Specific battery configuration and performance depend on selected model and options; consult technical datasheet or contact the supplier for exact configuration and availability.
