Planetary dough mixer TECNOMIX 130

with paddlefixed bowlwith metal protection grid

Short description
Compact planetary mixer with reduced dimensions, lightweight and easy to transport even in small vehicles. Designed for efficient mixing of pre-mixed or pre-dosed bagged products with minimal effort. The mixer provides uniform material homogeneity — no cement lumps in screeds or fiber clumps in fiber-reinforced products. The TECNOMIX 130 can also process traditional products when required, ensuring consistent yield and mixture uniformity.

Suitable for mixing

• Pre-mixed or traditional cement screeds, including fiber- or additive-reinforced mixes
• Pre-dosed lightweight screeds with expanded clay (<10 mm, 2 bags per cycle)
• Thermal insulation screeds (1 bag per cycle)
• Self-leveling subfloors (anhydrite/cement-based)
• Cement-, lime- or gypsum-based plasters
• Fiber-reinforced structural plasters with or without additives
• Renovation plasters
• Traditional plasters
• Injection mortars and binders
• Reinforcement mortars
• Bedding mortars (pre-mixed or traditional)
• Filling concrete (<8 mm aggregate size)
• Cement-based adhesives (large quantities)
• Smoothing mortars and finishing stuccos (large quantities)
• Waterproofing materials (large quantities)

Safety grind sensor
Electric device stops blade rotation when the drum grid is lifted. A low-voltage coil prevents accidental restart after power failure. All moving mechanical parts are guarded against accidental contact.

Discharge spout
Optimized discharge spout for easy emptying of the mixed material. Anti-intrusion grid protects the operator from accidental contact with the mixing blades.

Adjustable legs
Extendable legs allow adjustment of the discharge height for emptying into a wheelbarrow or plastering machine.

Gear motor with oil-bath gears
Robust gear motor with oil-bath gears reduces noise levels, improving operator comfort during prolonged use.

Easy handling
Compact layout, easy to manoeuvre on site and to load onto transport vehicles.

Blade assembly
The blade group comprises an external blade, an internal blade and a planetary blade, all rotating clockwise. The blade system can be fully disassembled for maintenance and cleaning by pressing the release mechanism and rotating counterclockwise.

Paint finish
Powder-coated with epoxy-polyester thermosetting paint to ensure good gloss, resistance to atmospheric agents and environmental compliance.

Technical specifications (table)
Model | 130 | 400
Drum capacity (L) | 130 | 400
Effective output (L) | 100 | 280
Drum diameter (mm) | 700 | 1000
Blade rotation speed (rpm) | 32 | 32
Machine weight (kg) | 100 | 350
Wheel size / model (mm) | 250 | 135 / R13
Motor power (hp) | 2.5 | 5.5
Length (mm) | 810 | 1550
Width (mm) | 770 | 1300
Height (mm) | 1210 (1030) | 1550 (1230)

Technical features / specifications

• Model: TECNOMIX 130
• Drum capacity: 130 L
• Effective output: 100 L
• Drum diameter: 700 mm
• Blade rotation speed: 32 rpm
• Machine weight: 100 kg
• Wheel size: 250 mm
• Motor power: 2.5 hp
• Length: 810 mm
• Width: 770 mm
• Height: 1210 mm (alternative figure: 1030 mm)
