Peristaltic pump
for chemicalsleverself-priming

Peristaltic pump - PERS GROUP - for chemicals / lever / self-priming

Peristaltic pump - PERS GROUP - for chemicals / lever / self-priming - image - 2

Peristaltic pump - PERS GROUP - for chemicals / lever / self-priming - image - 3

Peristaltic pump - PERS GROUP - for chemicals / lever / self-priming - image - 4

Add to favorites

Compare this product

Characteristics

Technology: peristaltic
Fluid: for chemicals
Operation: lever
Priming: self-priming
Mobility: stationary
Domain: industrial
Applications: dosing, feed
Material: stainless steel
Fluid specification: for corrosive fluids
Voltage: 400 V
Protection level: IP55
Flow: 200 l/h
(52.83441 us gal/h)
Pressure: 15 bar
(217.557 psi)
Power: 0.55 kW
(0.75 hp)
Length: 700 mm
(28 in)
Width: 600 mm
(23.62 in)
Height: 500 mm
(19.69 in)

Description

The dosing unit for automatically adding compound to water in a certain percentage (normally between 1% and 5%.) The fresh water and compound is mixed and then added to the system as required. The peristaltic pump which Pers Group recommend is running with an average of 42 rpm @ 50 Hz and pumps 200 L./h. The pump is a 0,55 kW and requires 3 x 400 V AC. The protection class is IP55. The peristaltic pump has the following measurements: L x W x H: 700 x 600 x 500 mm. and is supplied on 4 pieces of stainless-steel machine feet. NOTE: All other pump types will stall due to the amount of sludge in the waste water which the pump has to pump ADVANTAGE: • No mechanical seals or fillings • Robust box • Damage-free continuously dry running • Very easy to service • Robust ball bearings – greased for life
