Ball valve RAF 01manualhydraulically-operatedshut-off
Add to favorites
Compare this product
Characteristics
- Type
- ball
- Operation
- manual, hydraulically-operated
- Function
- shut-off
- Media
- for water
- Body
- flange, threaded
- Number of channels
- 3-way
- Other characteristics
- normally closed
- DN
Max.: 400 mm
(15.748 in)Min.: 25 mm
(0.984 in)- Pressure
10 bar, 16 bar
(145 psi, 232.1 psi)- Temperature
70 °C
(158 °F)
Description
The RAF 01 manual valve is a Normally Closed (N.C) line pressure hydraulically actuated.
The 3-W selecting cock valve changes positions: The RAF 01 valve opens when 3-W selecting cock valve is turned to position "0".
The RAF 01 shuts off when 3-W selecting cock valve is turned to position "C". The 3-W ball valve configuration together with Raphael's patented diaphragm enables smooth opening and surge free shut off.
