inspection device
WK-2/HD

Add to MyDirectIndustry favorites
inspection device inspection device - WK-2/HD
{{requestButtons}}

Description

Key features:

- Inspection hoists WK-1/HD (single post) and WK-2/HD (double post) are designed for inspection and assembly of venetian blinds, wooden blinds and exterior shutters.
- Machine frame is made of steel and anodized aluminium profiles.
- Height controllable with pedals.
- Machine equipped with an inverter for a smooth start and stop.
- An additional sliding brake locks the horizontal bar in case of technical problems.

Specifications:

Standard overall dimensions: 3000 x 3000 x 800 mm (118.1"/118.1"/31.4")
Lifting speed: ~0,3 m/s (11.8" ft/s)
Lifting height: 2700 mm (106.2")
Voltage: 1~230 V / 3~400 V
Wattage: 1.1 kW
Maximum bearing capacity: 50 kg (110 lbs)
